42
Great Planes ElectriFly ™ Extra 330S 3D ARF
Performance equals fun – and the Extra 330S EP ARF offers
plenty of both! What’s more, performance can be tailored to
the pilot’s preference. Drop in an out-runner and it’s a 3D
thriller, ready for an afternoon of torque rolls, waterfalls, and
harriers. And best of all, pilots can have the performance they
want after just 6-8 hours of simple, straightforward assembly!
The cowl, landing gear and wheel pants are painted to match
the high-quality, iron-on covering on prebuilt wood sections.
Hardware is included and designed to bring out the best in
E-Performance planes! GPMA1543
O.S. Engines ® 1.60 FX Ringed Engine
The 1.60 FX features dual ball bearings for durability and
smooth operation, plus a low crankcase profi le that allows for a
proportionally taller, semi-squared head – a design refi nement
that increases cooling fi n area and improves heat dispersion.
The threaded portion of the crankshaft is extra-long for more
secure prop and spinner nut engagement, and the needle valve
is remotely mounted for safety during adjustments. The high-
speed needle can also be mounted horizontally, vertically, or
separate from the engine for more installation options! Includes
glow plug and 2-year warranty. OSMG0661
Fuji-Imvac ™ BT-43EI-2 Gasoline Engine w/Electronic
Ignition System
The BT-43EI-2 design results in an engine that’s small
and light, but still delivers excellent power-to-weight ratio.
It features Fuji-Imvac’s popular Electronic Ignition System,
which offers reliable starting in a much smaller size and
weight than typical magneto systems. A Velocity Stack on
the Walbro carb increases air fl ow to help push fuel into the
chamber. Three bearings – one front, two center – help to
lessen vibration. The spinner bolt is predrilled and tapped for
attaching a prop adapter. The Friction Disk Pad is an added
safety feature that helps keep the prop from slipping on the
prop hub. With its innovative back plate, you can bolt the
engine directly to the fi rewall – no mounting plate required!
That makes mounting easier, as well as lowering overall
weight and vibration. FJIG0144
Fuji-Imvac is not related to the original Fuji Engines sold by Mecoa.
Great Planes ElectriFly RimFire ™ 63-62-250kV
Out-Runner Brushless Motor
ElectriFly RimFire brushless motors are designed and
produced with high quality, power, precision and effi ciency
in mind. The out-runner design eliminates the need for an
external gear drive for many applications, reducing cost, all-up
weight and complexity. And the RimFire’s prop saver design
eliminates the need for a prop adapter – simply strap the prop
onto the motor with a rubberband and that’s it! GPMG4795
• Exceptionally high power-to-weight ratio.
• Maximum rated effi ciency of 89%
• Extremely strong neodymium “rare earth” magnets for high
output torque, with one of the highest temperature ratings
in R/C at 302° F (150° C). They won’t break down like lower
quality magnets.
• Very reliable and virtually maintenance-free. No brushes to
wear out. Dual ball bearings are shielded on both sides to
keep out dirt and debris.
Futaba ® 6EX 2.4GHz Computer Radio
Once you’ve experienced the 6EX 2.4GHz FASST system,
you won’t want to fly any other way! The secret is the all-
