Page 78

5 : 5
7 : 3
F5/B5
F7/B3
Forward side
Brake side
Forward side
Brake side
78
Fu
n
c
tio
n
Throttle Mode "THR MODE"
This menu has the following 4 functions:
- Servo neutral mode, which sets the throttle neutral ratio to 7:3 or 5:5
- Idle up, which raises the idling speed when starting the engine to improve engine start-
ing performance of a gasoline car (boat)
- Neutral brake, which applies the brakes at the neutral position of the throttle trigger
- Throttle off (engine cut), which stops the engine of a boat, etc. by operating the throttle
servo to the low side regardless of the position of the throttle trigger.
Display the Throttle mode function screen as described on P64.
Throttle servo neutral position "SXNT"
-This function allows selection of the forward side and brake (reverse) side operation ra-
tio from 7:3 or 5:5 by changing the neutral position of the throttle servo.
Throttle Mode "THR MODE"
(Throttle system)
Setup item selection
- Select by by (UP) or (DN) button.
Setup items
SXNT
Throttle servo neutral position
IDLUP
Idle-Up rate
NTBRK
Neutral brake rate
THOFF
Throttle off (engine cut) position
1
(Mode selection)
Select the setting item "SXNT" by (UP) or (DN) button. Select
"F5/B5" or "F7/B3" by (+) or (-) button.
"F5/B5"
=Forward 50% : Back50%
"F7/B3"
=Forward 70% : Back30%
2
When ending, return to the ADVANCE menu screen by
pressing the (CT) button.
Selecting the throttle servo neutral position
Mode selection (SXNT)
F5/B5, F7/B3
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
