Futaba 4PL 2.4GHz FHSS - Manual (Page 74)

Front side only
4WS OFF
Same phase Reverse phase Rear side only
The function select switch screen
(P62) can be displayed from this
screen.
< NO SW >
If function’s ON/OFF switch is not
selected, is displayed.
74
Fu
n
c
tio
n
4WS Mixes 4WS) "4WS-MIX"
This function can be used with crawlers and other 4WS type vehicles. It is mixing which
uses the 1st CH to control the front side steering and the 3rd CH to control the rear side
steering.
OFF (front side only), reverse phase, same phase, rear side only and other 4WS type
switching is used by selecting SW1.PSH with the function select switch function (P62).
If not selected, is displayed. Therefore, select SW1.PSH.
Display the 4WS mixing screen as described on P64.
4WS Mixes "4WS MIX" (Steering, 3rd channel system)
Setup item selection
- Select by by (UP) or (DN) button.
Setup items
MODE
4WS Type
RATE 3ch rate (Rear side)
MXMD Mix mode
