Futaba 4PL 2.4GHz FHSS - Manual (Page 62)

CT CT CT
(HOME screen) (MENU screen) (DIAL SW screen) (Function Switch screen)
Select MENU
Function selection
Direction of operation setting
62
Fu
n
c
tio
n
Function Select Switch "SWITCH"
Selection of the function to be performed by push switch (SW1.PSH, PS2.SLD) and
operation system setting can be performed by this function.
- The functions that can be assigned to each switch are listed on the next page.
- SW1.PSH alternate operation (operation which switches between ON and OFF
each time the switch is pressed) is possible.
NOR (Normal) -ON only while pressed, OFF when released.
ALT (Alternate) -Switched between ON and OFF each time pressed.
Display the function select switch screen by as follows:
1
(Setting SW selection)
Select the SW you want to set by (UP) or (DN) button.
2
(Function setting)
Select the function with the (+) or (-) button.
-Refer to the list for the abbreviations of the functions.
(Changing the SW1.PSH operation system)
Select DIR of
button.
Select ALT or NOR with the (+) or (-) button.
3
When ending setting return to the DIAL SW screen by
pressing the (CT) button. To return to the menu screen, se-
lect
ton and to return to the HOME screen select by (UP)
or (DN) button and press the (CT) button.
Function select switch setting
Function Select Switch "SWITCH"
Adjust button
Adjust with the (+) and (-) but-
tons.
