Futaba 4PL 2.4GHz FHSS - Manual (Page 73)

73
Fu
n
c
tio
n
Brake Mixing "BRAKE"
1
(Brake mixing function ON/OFF)
Using the (UP) or (DN) button, select "MODE" of for
CH3 brake and "MODE" of for CH 4 brake.
Press the (+) or (-) key and set the function to the "ACT"
state.
"INH" : Function OFF
"ACT" : Function ON
- When "(4WS>OFF)" is displayed below ABS, the CH3 brake can-
not be used if the 4WS function is not set to "ACT".
- When "(ESC>INH) is displayed under ABS, the CH4 brake cannot
be used if the dual ESC function is not set to "INH".
2
(Brake rate)
Using the (UP) or (DN) button, select "RATE" of for
CH3 brake and "RATE" of for CH 4 brake , and use
the (+) and (-) buttons to adjust the Brake rate amount.
3
(Delay amount setup)
Using the (UP) or (DN) button, select "DELY" of for
CH3 brake, "DELY" of for CH 4 brake and "DELY" of
for CH 2 brake. Use the (+) and (-) buttons to adjust
the delay amount.
"0" : No delay
"100" : Maximum delay amount
4
(3rd & 4th channels brake-A.B.S ON/OFF)
Using the (UP) or (DN) button, select "ABS" of for
CH3 brake and "ABS" of for CH 4 brake.
Press the (+) or (-) key and set the function to the "ACT"
state.
5
When ending, return to the ADVANCE menu screen by
pressing the (CT) button.
Brake mixing adjustment
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
Brake rate (RATE)
0 ~ 100
Initial value:100
Delay amount (DELY)
(CH3) 0 ~ 100
(CH4) 0 ~ 100
(CH2) 0 ~ 100
Initial value:0
Function ON/OFF (MODE)
INH, ACT
Function ON/OFF (ABS)
INH, ACT
The function select dial function can control the 3rd/4th channels. Brake rate (RATE)
can be controlled with digital dial or digital trim, using the function select dial func-
tion. (See page 60)
Dial / Trim Setting
To use CH3 of the brake mixing function, 4WS mixing (P74) must be set to "INH" and
to use CH4, the dual ESC function must be set to "INH"
Setting the 4WS mixing/dual ESC function
