Fu n c tio n, The steering speed adjustment, Turn – Futaba 4PL 2.4GHz FHSS User Manual
Page 55: Retn

TU
RN TURN
R
ET
UR
N RETU
RN
55
Fu
n
c
tio
n
(Preparation)
- On the STEERING 1 screen, display the
STEERING 2 screen by (UP) or (DN) button
and make the following adjustments:
1
"TURN" direction adjustment
Select the setting item "TURN" by (UP) or
(DN) button, and use the (+) or (-) buttons to
adjust the delay amount.
2
"RETURN" direction adjustment
Select the setting item "RETN" by (UP) or
(DN) button, and use the (+) or (-) buttons to
adjust the delay amount.
3
When ending, return to the menu screen by pressing the (CT)
button.
Steering Speed adjustment
100%
1%
Servo operation is delayed.
- Onroad TURN side: Approx. 50~80% RETURN side: Approx. 60~100%
- Offroad TURN side: Approx. 70~100% RETURN side: Approx. 80~100%
Setting example (Steering servo: BLS451 / BLS351) . . . (Setting criteria)
Adjust button
- Adjust with the (+) and (-) but-
tons.
- Return to the initial value "100"
by pressing the (+) and (-) but-
tons simultaneously for about 1
second.
The steering speed adjustment
"
TURN
"
and
"
RETN
"
can be controlled with digital dial
or digital trim. With the function select dial function. (See page 60)
Dial / Trim Setting
Adjustment range
1~100% (each direction)
At 100%, there is no delay.
Throttle Speed "SPEED"
