30
Note
DC 5V power adapter AC100 / AC100 Plus Power button
2 TCP/IP Port
A straight RJ45 cable is used to connect to a network
switch/hub. A crossover RJ45 cable is used to con-
nect directly to a PC network port.
3 Power Adapter Port
Plug in the power adapter provided to get for power supply to the unit.
4 USB port
Please connect the USB extention provided into this port when you want to upload or down-
load data into USB flash disk.
STARTUP AND SHUTDOWN
1. Connect DC 5V power adapter to to the FingerTec® AC100 or AC100 Plus models.
2. Turn on the power supply.
3. Press the power button to switch on or shutdown the reader.
RJ45 is not included
in FingerTec® AC100
package.
