20
Options 6
System Opt
Power Mng
4 Comm Opt
Options 6
Power Mng
Comm Opt
4 Log Opt
COMMUNICATION OPTION
This is to configure communication settings of FingerTec® readers. User
can choose the type of communication (TCP/IP, RS232 or RS458). Im-
proper settings will cause connection to computer to fail.
Those options are:
Baud rate to adjust baud rate of connection with RS232 or RS485
Dev num the number of reader in an installed environment
IP Addr to configure the IP address of reader
Net speed to adjust the speed connection of Ethernet
Netmask to configure netmask to suit reader into local area network.
Gateway to configure gateway to suit reader into local area network.
Ethernet to enable or disable Ethernet as communication method
RS 232 to enable or disable RS232 as communication method
RS 485 to enable or disable RS485 as communication method
COMM key communication key between reader and software, always set to “0”
LOG OPTION
If FingerTec® reader has capacity storage limit of a maximum 100,000
transaction logs and to ensure that all transactions are intact in the
reader, user can adjust the warning level of transaction storage to for
example 40,000 or 45,000. When the transaction storage reaches the
warning level, FingerTec® reader will alert users with a beep.
Alm SuperLog to instruct reader to alert user if the transaction storage of administrator login is less
than as configured, default is 99.
Alm AttLog to instruct reader to alert user if the transaction storage is less than as configured,
default is 99.
ReCheck Min to instruct reader to update clocking times of all user in a time interval, default is 10
minutes.
