15 CONFIGURATION PARAMETERS
15.1 Configuration parameters
PAR.
MIN MAX U. M. EVC30..00 EVC30..01 EVC30..02 EVC30..03 EVC30..04 EVC30..05 EVC70..00 EVC70..01 EVC70..02 EVC70..03
P0 0 1 - - - - 0 0 0 0 0 0 - - - - - - - - - - - - - - - -
P0 P1 P2 min - - - - - - - - - - - - - - - - - - - - - - - - 20 - - - - - - - - 20
P0 P1 P2 s/min (2) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10 10 - - - -
P1 -9 9 °C 0 0 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P1 -9 9 °C - - - - - - - - 0 0 0 0 - - - - - - - - - - - - - - - -
P1 0 P2 min. - - - - - - - - - - - - - - - - - - - - - - - - 0 - - - - - - - - 0
P1 0 P2 s/min (2) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 0 0 - - - -
P2 P3 P4 °C 10 10 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P2 -9 9 °C - - - - - - - - 0 0 0 0 - - - - - - - - - - - - - - - -
P2 P1 999 min - - - - - - - - - - - - - - - - - - - - - - - - 199 - - - - - - - - 199
P2 P1 999 s/min (2) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 999 999 - - - -
P3 20 P4 °C 0 0 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P3 0 1 - - - - - - - - - - - - 0 0 0 0 - - - - - - - - - - - - - - - -
P3 0 60 s - - - - - - - - - - - - - - - - - - - - - - - - 20 - - - - - - - - 20
P3 P4 P5 s/min (2) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10 10 - - - -
P4 P3 450 °C 450 450 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P4 2 9 °C - - - - - - - - 2 2 2 2 - - - - - - - - - - - - - - - -
P4 0 240 s - - - - - - - - - - - - - - - - - - - - - - - - 10 - - - - - - - - 10
P4 0 P5 s/min (2) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 0 0 - - - -
P5 2 9 °C 2 2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P5 0 P6 °C - - - - - - - - 0 0 0 0 - - - - - - - - - - - - - - - -
P5 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - • - - - - - - - - •
P5 P4 999 s/min (2) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 999 999 - - - -
P6 0 1 - - - - 0 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P6 0 600 - - - - - - - - 0 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P6 P5 450 °C - - - - - - - - 400 400 400 400 - - - - - - - - - - - - - - - -
P6 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - • - - - - - - - - •
P6 P7 P8 s/min (2) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10 10 - - - -
P7 55 65 °C 60 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P7 0 600 s - - - - 0 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P7 P5 P6 °C - - - - - - - - 200 200 200 200 - - - - - - - - - - - - - - - -
P7 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - • - - - - - - - - •
P7 0 P8 s/min (2) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 0 0 - - - -
P8 0 1 - - - - 0 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P8 0 1 - - - - - - - - 0 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P8 P5 P6 °C - - - - - - - - 200 200 200 200 - - - - - - - - - - - - - - - -
P8 P7 999 s/min (2) - - - - - - - - - - - - - - - - - - - - - - - - - - - - 999 999 - - - -
P9 - - - - - - - - - - - - • - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P9 55 65 °C - - - - 60 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P9 0 2 - - - - - - - - - - - - 0 0 0 0 - - - - - - - - - - - - - - - -
P9 0 1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 0 0 - - - -
P10 - - - - - - - - - - - - • - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P10 0 1 - - - - - - - - 0 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P10 1 999 s - - - - - - - - 60 60 60 60 - - - - - - - - - - - - - - - -
P10 0 2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 0 0 - - - -
P11 - - - - - - - - - - - - • - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P11 - - - - - - - - - - - - - - - - • - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P11 P5 P6 °C - - - - - - - - 200 200 200 200 - - - - - - - - - - - - - - - -
P11 1 10 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 1 - - - -
P12 - - - - - - - - - - - - - - - - • - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
P12 0 100 % - - - - - - - - 70 70 70 70 - - - - - - - - - - - - - - - -
P12 0 60 s - - - - - - - - - - - - - - - - - - - - - - - - - - - - 0 0 - - - -
P13 - - - - - - - - - - - - - - - - • - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
DESCRIPTION
temperature unit of measurement (1)
0 = °C
1 = °F
predefined cooking timer value
time t1 predefined value
chamber probe offset
if P3 = 0, top probe offset
if P3 = 1, chamber probe offset
cooking timer minimum value
time t1 minimum value
work set point predefined value
floor probe offset (only if P3 = 0)
cooking timer maximum value
time t1 maximum value
minimum work set-point
type of functioning
0 = with 2 measurement inputs (allows to set the top work temperature
independently from that of the floor )
1 = with 1 measurement input (allows to set the power supplied at the
top independently from that supplied at the bottom)
during activation of the buzzer on conclusion of the cooking timer count;
also see P24
time t3 predefined value
maximum work set-point
if P3 = 0, top set point differential and of the floor set point
if P3 = 1, work set point differential
time that passes between the activation of the buzzer and the conclusion
of the cooking timer count, see also P3
time t3 minimum value
work set-point differential
if P3 = 0, minimum top set point and floor set point
if P3 = 1, minimum work set point
firmware code (3)
time t3 maximum value
enabling of the use temperature alarm (code “H-t”)
1 = YES
duration of auxiliary output switch-on; see also P7
if P3 = 0, maximum top set point and floor set point
if P3 = 1, maximum work set point
firmware version code (3)
time t2 predefined value
temperature over which the use temperature alarm is activated
(code “H-t”); see also P6
duration of auxiliary output switch-off; see also P6
predefined value of the top set point (only if P3 = 0)
firmware revision code (3)
time t2 minimum value
size displayed when the instrument is on
0 = work set point
1 = chamber temperature
enabling of the use temperature alarm (code “H-t”)
1 = YES
predefined value of the floor set point (only if P3 = 0)
time t2 maximum value
firmware code (3)
temperature over which the use temperature alarm is activated
(code “H-t”); see also P8
effect between the power supplied at the top and that at the floor
0 = no effect
1 = the modification of the power supplied at an output automatically
causes the supply of the maximum power at the other
2 = the modification of the power supplied at an output causes an
automatic adaptation of the power supplied at the other in order to
guarantee that he sum of the two percentages is always 100
unit of measurement of times P0, P1, P2, P3, P4, P5, P6, P7 and P8
0 = second
1 = minute
firmware version code (3)
size displayed when the instrument is on
0 = work set point
1 = chamber temperature
cycle time for switch-on of the top output and the floor output; see also
P12 and P13 (only if P3 = 1)
functioning of the instrument at the conclusion of the time t3 count.
0 = the instrument switches off
1 = the steam sequence is repeated automatically for the number of times
established with parameter P11
2 = the steam sequence is repeated automatically until it is interrupted by
pressing key B6
firmware revision code (3)
firmware code (3)
predefined value of the work set point (only if P3 = 1)
number of steam sequence (only if P10 = 1)
firmware version code (3)
predefined value of the power supplied at the top (percentage of P10;
only if P3 = 1); see also P9
duration of the activation of the buzzer on conclusion of the time t3 count
firmware revision code (3)
