Evco S.p.A. • Code 104C30S40E02 • page 4/6
PT • 39/10
Consequences:
• all outputs will be deactivated
H-t For EVC30S40J7XXX02 / 03 / 04 / 05.
use temperature alarm
Solutions:
• press B2 to display the use temperature
• see parameters P14 and P15
Consequences:
• all outputs will be deactivated
When the cause of the alarm has disappeared, the instrument restores
normal functioning, except for the use temperature alarm
(code “H-t”), which requires the B1 key to be pressed or the encoder
button). This switches the instrument off.
13
INTERNAL DIAGNOSTICS
13.1 Internal diagnostics
CODE MEANING
AL1 For EVC30S40J7XXX00 / 01.
chamber probe error
Solutions:
• check that the probe is a J thermocouple
• check the integrity of the probe
• check the instrument-probe connection
• verify the chamber temperature
Main consequences:
• the temperature regulation output will be deactivated
AL1 For EVC30S40J7XXX02 / 03 / 04 / 05 (if parameter P3 is set
at 0).
top probe error
Solutions:
• the same as the previous case but relative to the top probe
Main consequences:
• the top output will be deactivated
For EVC30S40J7XXX02 / 03 / 04 / 05 (if the parameter P3
is set at 1).
chamber probe error
Solutions:
• the same as the previous case but relative to the chamber
probe
Main consequences:
• the top output and the floor output will be deactivated
AL2 For EVC30S40J7XXX02 / 03 / 04 / 05 (if parameter P3 is set
at 0).
floor probe error
Solutions:
• the same as the previous case but relative to the floor
probe
Main consequences:
• the floor output will be deactivated
When the causes of the alarm have disappeared, the instrument will
go back to normal functioning.
14
TECHNICAL DATA
14.1 Technical data
With reference to the model with most hardware.
Container: open frame board
Front panel protection rating: IP 00.
Connections: 6.3 mm faston (0.248 in, power supply and outputs),
screw terminal board (measurement inputs), 4-pole connector (to the
encoder).
Temperature of use:from 0 to 55 °C (from 32 to 131 °F,
10 ... 90% relative humidity without condensate).
Power supply: 230 Vac, 50/60 Hz, 1.5 VA.
Alarm buzzer: incorporated.
Measurement inputs: 2 for J thermocouple; the instrument also
incorporates a sensor for the detection of the use temperature.
Range of measurement:from 20 to 500 °C (from 99 to 999 °F).
Resolution: 1 °C/1 °F.
Digital outputs: 2 5 A res. relays @ 250 Vac (NO).
