if functioning with 2 measurement inputs, the lower part of the dis-
play will show one of the labels given in the following table for 2
seconds:
LABEL MEANING
Pb1 temperature of the top
SP1 top set-point
tine value of the cooking timer or its count if the timer is active
Pb2 temperature of the floor
SP2 floor set-point
3.7 Temporary setting of the quantity shown by the
lower part of the display during the on state
• make sure no procedure is in progress
• press
and for 1s several times: the lower part of the display
will show one of the labels given in the tables in
paragraph 3.6 for 2 secs, after which it will show
the corresponding value.
Any power supply cut-off causes the display of the quantity estab-
lished with parameter P6 to be restored.
3.8
Chamber light switch on/off
• make sure no procedure is in progress
• press
Using the multifunction input, it is also possible to cause the same
effect caused by pressing the
key in remote mode.
If the chamber light is not managed by any digital output, pressing the
key will cause the display of the “no” indication for 1s in the lower
part of the display.
3.9
Buzzer silencing
• make sure no procedure is in progress
• press a key (the first time the key is pressed, the associated effect is not
caused).
Pressing the key also causes the deactivation of the acoustic output
and the buzzer output.
Using the multifunction input, it is also possible to deactivate the buzzer,
the acoustic output and the buzzer output in remote mode.
4
SETTINGS
4.1 Setting the type of functioning (with 1 measure-
ment input rather than 2)
To access the procedure:
• make sure that the instrument is in stand-by state and that no proce-
dure is in progress
• press and for 4s: the upper part of the display will show
“PA”
• press : the lower part of the display will show the correspond-
ing value
• press or within 15s to set “743”
• press
• press
and for 4s: the upper part of the display will show
“Pb”.
To modify the type of functioning:
• press
: the lower part of the display will show the correspond-
ing value.
The meaning of the values is the following:
VALUE MEANING
1 functioning with 1 measurement input (chamber probe)
2 functioning with 2 measurement inputs (top probe and
floor probe)
• press or within 15s
• press
To exit the procedure:
• press
and for 4s.
The modification of the type of functioning does not cause
the configuration parameters default value to be restored.
4.2
Setting the instrument code
To access the procedure:
• make sure that the instrument is in stand-by state and that no proce-
dure is in progress
• press and for 4s: the upper part of the display will show
“PA”
• press : the lower part of the display will show the correspond-
ing value
• press or within 15s to set “743”
• press
• press
and for 4s: the upper part of the display will show
“Pb”
• press or to select “CFG”.
To modify the instrument code:
• press
: the lower part of the display will show the correspond-
ing value
• press or within 15s
• press
To exit the procedure:
• press
and for 4s.
The modification of the instrument code does not cause
the configuration parameters default value to be restored.
4.3
Setting the utility managed by each digital output
(only if the instrument code is set at 0)
To access the procedure:
• make sure that the instrument is in stand-by state and that no proce-
dure is in progress
• press and for 4s: the upper part of the display will show
“PA”
• press : the lower part of the display will show the correspond-
ing value
• press or within 15s to set “743”
• press
• press
and for 4s: the upper part of the display will show “Pb”
• press or to select “do1”, “do2” or “do3”.
The label meaning is the following:
LABEL MEANING
do1 utility managed by the first digital output (relay K1)
do2 utility managed by the second digital output (relay K2)
do3 utility managed by the third digital output (relay K3)
To modify the utility managed by an output:
• press
: the lower part of the display will show the correspond-
ing value.
The meaning of the values is the following:
VALUE MEANING
0 not used
1 top
2 floor
3 airhole
4 steam injection
5 alarm
6 chamber light
7 cooking timer
8 acoustics
• press or within 15s
• press
To exit the procedure:
• press
and for 4s.
If the instrument code is not set at 0, display only is
allowed but not the modification of the value correspond-
ing to the utility managed by the output.
4.4.1 Setting the work set-point (only if functioning with
1 measurement input)
• make sure that the instrument is in on state and that no procedure is
in progress
• press : the lower part of the display will show “SP”, the upper
part the corresponding value and the LED
will flash
• press or within 15s; see also parameters r1 and r2
• press 3 times or do not operate for 15s: the LED will switch-
off, after which the instrument will exit the procedure.
To exit the procedure in advance:
• do not operate for 15s (any modifications will be saved).
It is also possible to set the work set-point via the SP parameter.
4.4.2 Setting the top set-point and the floor set-point
(only if functioning with 2 measurement inputs)
To modify the top set-point:
• make sure that the instrument is in on state and that no procedure is
in progress
• press : the lower part of the display will show “SP1”, the upper
part the corresponding value and the LED
will
flash
• press or within 15s; see also parameters r1 and r2
• press 2 times or do not operate for 15s: the LED will
switch-off, after which the instrument will exit the pro-
cedure.
To modify the floor set-point:
• press
during the modification of the top set-point: the lower
part of the display will show “SP2”, the upper part the
corresponding value and the LED
will flash
• press or within 15s; see also parameters r7 and r8
• press : the LED will switch-off, after which the instrument
will exit the procedure.
To go back to previous levels:
• press
several times during the procedure.
To exit the procedure in advance:
• do not operate for 15s (any modifications will be saved).
It is also possible to set the top set-point via parameter SP1 and the floor
set-point via parameter SP2.
4.5
Setting the power distributed to the top and the
power distributed to the floor (only if functioning
with 1 measurement input)
To modify the power distributed to the top:
• press
during the modification of the work set-point: the lower
part of the display will show “Po1”, the upper part the
corresponding value and a proportioned number of bars
of the LED will flash
• press or within 15s; see also parameters c0 and c1
• do not operate for 15s: the LED will switch-off, after which the
instrument will exit the procedure.
To modify the power distributed to the floor:
• press
during the modification of the power distributed to the
top: the lower part of the display will show “Po2”, the
upper part the corresponding value and a proportioned
number of bars of the LED will flash
• press or within 15s; see also parameters c0 and c1
• press : the LED will switch-off, after which the instrument will
exit the procedure.
To go back to previous levels:
• press
several times during the procedure.
To exit the procedure in advance:
• do not operate for 15s (any modifications will be saved).
It is also possible to set the power distributed to the top through pa-
rameter Po1 and the power distributed to the floor through param-
eter Po2.
4.6 Setting the configuration parameters
To access the procedure:
• make sure that the instrument is in stand-by state and that no proce-
dure is in progress
• press and for 4s: the upper part of the display will show “PA”
• press : the lower part of the display will show the correspond-
ing value
• press or within 15s to set “-19”
• press or do not operate for 15s
• press and for 4s: if functioning with 1 measurement input,
the upper part of the display will show “SP”; if
functioning with 2 measurement inputs, the
upper part of the display will show “SP1”.
To select a parameter:
• press
or
To modify a parameter:
• press
: the lower part of the display will show the correspond-
ing value
• press or within 15s
• press or do not operate for 15s.
To exit the procedure:
• press
and for 4s or do not operate for 60s (any modifica-
tions will be saved).
Cut the instrument power supply off after modification of
the parameters.
4.7
Restore the default value of the configuration pa-
rameters
• make sure that the instrument is in stand-by state and that no proce-
dure is in progress
• press and for 4s: the upper part of the display will show
“PA”
• press : the lower part of the display will show the correspond-
ing value
• press or within 15s to set “743”
• press or do not operate for 15s
• press and for 4s: the upper part of the display will show
“Pb”
• press or to select “dEF”
• press : the lower part of the display will show the correspond-
ing value
• press or within 15s to set “149”
• press or do not operate for 15s: the upper part of the display
will show “dEF” flashing for 4s, after which “dEF” will
switch on
• cut the instrument power supply off.
To exit the procedure in advance:
• press
and for 4s during the procedure (i.e. before setting
“149”: restore will not be carried out).
Make sure that the default value of the parameters is
appropriate.
5
COOKING TIMER
5.1 Preliminary considerations
The cooking timer allows to start the reverse count of a time.
The count is shown in the lower part of the display; during the count
the “timer” LED is on and the timer output is activated.
Before conclusion of the count (of the time established with parameter c9)
the buzzer and the acoustic output are activated, for the time estab-
lished with parameter c4.
Before conclusion of the count (of the time established with parameter c5)
the airhole is activated, for the time established with parameter c6.
Using the multifunction input, it is also possible to start/interrupt the
cooking timer in remote mode.
5.2
Setting the cooking timer
• make sure that the instrument is in the on state, that the cooking timer
count is not in progress and that no procedure is in progress
• press and : the lower part of the display will show the value
of the cooking timer; the left part and the “timer”
LED will flash.
The value of the cooking timer is displayed in the hours:minutes format.
To modify the hour:
• press
or within 15s
• press : the right part will flash.
To modify the minutes:
• press
or within 15s.
The cooking timer can be set between 00:00 and 24:00 h:min.
• press
: the “timer” LED will switch-off, after which the instru-
ment will exit the procedure.
To go back to previous levels:
• press
several times during the procedure.
To exit the procedure in advance:
• do not operate for 15s (any modifications will be saved).
The cooking timer can also be set when the count is in progress (this
modification is temporary, i.e. any power supply cut-off causes the
value set with the procedure given at the start of this paragraph to be
restored). If the value is set at 00:00 h:min, the count will be inter-
rupted, the “timer” LED will switch-off and the buzzer will be activated
for 3 seconds.
5.3
Starting the cooking timer
• press during timer setting: the “timer” LED will switch on.
Alternatively:
• make sure that the instrument is in on state and that no procedure is
in progress
• press : the “timer” LED will switch on.
