44
JB-07
12
RB15
PMALL/PMA0/AN15/OCFB/CN12/RB15
47
JE-01
32
RD14
CN20/U1CTS/RD14
48
JE-04
35
RD15
U1RTS/BCLK1/CN21/RD15
49
JH-03
50
RF04
PMA9/U2RX/CN17/RF4
50
JH-02
49
RF05
PMA8/U2TX/CN18/RF5
51
N/A
N/A
RF03
USBID/RF3
USB-4
52
JE-03
34
RF02
U1RX/RF2
53
JE-02
33
RF08
U1TX/RF8
56
N/A
N/A
RG03
D-/RG3
USB-2
57
N/A
N/A
RG02
D+/RG2
USB-3
58
J6-1,J6-2
72
RA02
SCL2/RA2
I2C2
59
J6-3,J6-4
73
RA03
SDA2/RA3
I2C2
60
JF-09
46
RA04
TDI/RA4
61
JF-10
47
RA05
TDO/RA5
63
N/A
N/A
RC12
OSC1/CLKI/RC12
Primary Oscillator
64
N/A
N/A
RC15
OSC2/CLKO/RC15
Primary Oscillator
66
JF-01
40
RA14
SCL1/INT3/RA14
also J2-01,J2-02 I2C1
67
JF-02
41
RA15
SDA1/INT4/RA15
also J2-03,J2-04 I2C1
68
JH-09
54
RD08
IC1/RTCC/RD8
also J1-08
69
JD-03
26
RD09
IC2/SS1/RD9
also J1-01
70
JD-09
30
RD10
IC3/SCK1/PMCS2/PMA15/RD10
also J1-04
71
JE-09
38
RD11
IC4/PMCS1/PMA14/RD11
72
JH-08
53
RD00
SDO1/OC1/INT0/RD0
also J1-02
73
N/A
N/A
RC13
SOSCI/CN1/RC13
Secondary Oscillator
74
N/A
N/A
RC14
SOSCO/T1CK/CN0/RC14
Secondary Oscillator
76
JD-02
25
RD01
OC2/RD1
77
JD-08
29
RD02
OC3/RD2
78
JE-08
37
RD03
OC4/RD3
79
JK-09
70
RD12
PMD12/IC5/RD12
80
JH-10
55
RD13
PMD13/CN19/RD13
also J1-09
81
JB-09
14
RD04
PMWR/OC5/CN13/RD4
82
JB-08
13
RD05
PMRD/CN14/RD5
83
JD-07
28
RD06
PMD14/CN15/RD6
also J1-10
84
JD-01
24
RD07
PMD15/CN16/RD7
87
JC-09
22
RF00
PMD11/RF0
also servo S7
88
JC-10
23
RF01
PMD10/RF1
also servo S8
89
JC-08
21
RG01
PMD9/RG1
also servo S6
90
JC-07
20
RG00
PMD8/RG0
also servo S5
91
JF-03
42
RA06
TRCLK/RA6
also BTN1
92
JF-04
43
RA07
TRD3/RA7
also BTN2
