Digilent Parallel Interface Model

Digilent, Inc.

www.digilentinc.com

Copyright Digilent, Inc.

Page 7

signal

ctlEppAstb : std_logic;

signal

ctlEppDstb : std_logic;

signal

ctlEppDir

: std_logic;

signal

ctlEppWr

: std_logic;

signal

ctlEppAwr

: std_logic;

signal

ctlEppDwr

: std_logic;

signal

busEppOut

: std_logic_vector(7 downto 0);

signal

busEppIn

: std_logic_vector(7 downto 0);

signal

busEppData : std_logic_vector(7 downto 0);


-- Registers

signal

regEppAdr

: std_logic_vector(3 downto 0);

signal

regData0

: std_logic_vector(7 downto 0);

signal

regData1

: std_logic_vector(7 downto 0);

signal regData2

: std_logic_vector(7 downto 0);

signal regData3

: std_logic_vector(7 downto 0);

signal regData4

: std_logic_vector(7 downto 0);

signal

regData5

: std_logic_vector(7 downto 0);

signal

regData6

: std_logic_vector(7 downto 0);

signal

regData7

: std_logic_vector(7 downto 0);

signal

regLed

: std_logic_vector(7 downto 0);


signal

cntr

: std_logic_vector(23 downto 0);


------------------------------------------------------------------------
-- Module Implementation
------------------------------------------------------------------------

begin

------------------------------------------------------------------------

-- Map basic status and control signals

------------------------------------------------------------------------

clkMain <= mclk;


ctlEppAstb <= astb;

ctlEppDstb <= dstb;

ctlEppWr <= pwr;

pwait <= ctlEppWait; -- drive WAIT from state machine output


-- Data bus direction control. The internal input data bus always

-- gets the port data bus. The port data bus drives the internal

-- output data bus onto the pins when the interface says we are doing

-- a read cycle and we are in one of the read cycles states in the

-- state machine.

busEppIn <= pdb;

pdb <= busEppOut when ctlEppWr = '1' and ctlEppDir = '1' else "ZZZZZZZZ";

-- Select either address or data onto the internal output data bus.

busEppOut <= "0000" & regEppAdr when ctlEppAstb = '0' else busEppData;


rgLed <= regLed;

ldg <= '1';


-- Decode the address register and select the appropriate data register

busEppData <= regData0 when regEppAdr = "0000" else

regData1 when regEppAdr = "0001" else

regData2 when regEppAdr = "0010" else
