end if;
end process;
------------------------------------------------------------------------
-- EPP Data registers
------------------------------------------------------------------------
-- The following processes implement the interface registers. These
-- registers just hold the value written so that it can be read back.
-- In a real design, the contents of these registers would drive additional
-- logic.
-- The ctlEppDwr signal is an output from the state machine that says
-- we are in a 'write data register' state. This is combined with the
-- address in the address register to determine which register to write.
process (clkMain, regEppAdr, ctlEppDwr, busEppIn)
begin
if clkMain = '1' and clkMain'Event then
if ctlEppDwr = '1' and regEppAdr = "0000" then
regData0 <= busEppIn;
end if;
end if;
end process;
process (clkMain, regEppAdr, ctlEppDwr, busEppIn)
begin
if clkMain = '1' and clkMain'Event then
if ctlEppDwr = '1' and regEppAdr = "0001" then
regData1 <= busEppIn;
end if;
end if;
end process;
process (clkMain, regEppAdr, ctlEppDwr, busEppIn)
begin
if clkMain = '1' and clkMain'Event then
if ctlEppDwr = '1' and regEppAdr = "0010" then
regData2 <= busEppIn;
end if;
end if;
end process;
process (clkMain, regEppAdr, ctlEppDwr, busEppIn)
begin
if clkMain = '1' and clkMain'Event then
if ctlEppDwr = '1' and regEppAdr = "0011" then
regData3 <= busEppIn;
end if;
end if;
end process;
process (clkMain, regEppAdr, ctlEppDwr, busEppIn)
begin
if clkMain = '1' and clkMain'Event then
if ctlEppDwr = '1' and regEppAdr = "0100" then
regData4 <= busEppIn;
end if;
end if;
end process;
