Example Source Code:

The following is an example of the interface implemented in VHDL.

----------------------------------------------------------------------------
-- DPIMREF.VHD -- Digilent Parallel Interface Module Reference Design
----------------------------------------------------------------------------
-- Author: Gene Apperson
-- Copyright 2004 Digilent, Inc.

----------------------------------------------------------------------------
-- This module contains an example implementation of Digilent Parallel
-- Interface Module logic. This interface is used in conjunction with the
-- DPCUTIL DLL and a Digilent Communications Module (USB, EtherNet, Serial)
-- to exchange data with an application running on a host PC and the logic
-- implemented in a gate array.
--
-- See the Digilent document, Digilent Parallel Interface Model Reference
-- Manual (doc # 560-000) for a description of the interface.
--

-- This design uses a state machine implementation to respond to transfer
-- cycles. It implements an address register, 8 internal data registers
-- that merely hold a value written, and interface registers to communicate
-- with a Digilent DIO4 board. There is an LED output register whose value
-- drives the 8 discrete leds on the DIO4. There are two input registers.
-- One reads the switches on the DIO4 and the other reads the buttons.
--
-- Interface signals used in top level entity port:
--

mclk

- master clock, generally 50Mhz osc on system board

--

pdb

- port data bus

--

astb

- address strobe

--

dstb

- data strobe

--

pwr

- data direction (described in reference manual as WRITE)

--

pwait

- transfer synchronization (described in reference manual

--

as WAIT)

--

rgLed

- LED outputs to the DIO4

--

rgSwt

- switch inputs from the DIO4

--

ldb

- led gate signal for the DIO4

--

rgBtn

- button inputs from the DIO4

--

btn

- button on system board (D2SB or D2FT)

--

led

- led on the system board

--

----------------------------------------------------------------------------
-- Revision History:
-- 06/09/2004(GeneA): created
-- 08/10/2004(GeneA): initial public release
----------------------------------------------------------------------------

library IEEE;

use IEEE.STD_LOGIC_1164.ALL;
use IEEE.STD_LOGIC_ARITH.ALL;
use IEEE.STD_LOGIC_UNSIGNED.ALL;

-- Uncomment the following lines to use the declarations that are
-- provided for instantiating Xilinx primitive components.
--library UNISIM;
--use UNISIM.VComponents.all;

entity dpimref is
