Port (
mclk : in std_logic;
pdb : inout std_logic_vector(7 downto 0);
astb : in std_logic;
dstb : in std_logic;
pwr : in std_logic;
pwait : out std_logic;
rgLed : out std_logic_vector(7 downto 0);
rgSwt : in std_logic_vector(7 downto 0);
rgBtn : in std_logic_vector(4 downto 0);
btn : in std_logic;
ldg : out std_logic;
led : out std_logic
);
end dpimref;
architecture Behavioral of dpimref is
------------------------------------------------------------------------
-- Component Declarations
------------------------------------------------------------------------
------------------------------------------------------------------------
-- Local Type Declarations
------------------------------------------------------------------------
------------------------------------------------------------------------
-- Constant Declarations
------------------------------------------------------------------------
-- The following constants define state codes for the EPP port interface
-- state machine. The high order bits of the state number give a unique
-- state identifier. The low order bits are the state machine outputs for
-- that state. This type of state machine implementation uses no
-- combination logic to generate outputs which should produce glitch
-- free outputs.
constant stEppReady : std_logic_vector(7 downto 0) := "0000" & "0000";
constant stEppAwrA : std_logic_vector(7 downto 0) := "0001" & "0100";
constant stEppAwrB : std_logic_vector(7 downto 0) := "0010" & "0001";
constant stEppArdA : std_logic_vector(7 downto 0) := "0011" & "0010";
constant stEppArdB : std_logic_vector(7 downto 0) := "0100" & "0011";
constant stEppDwrA : std_logic_vector(7 downto 0) := "0101" & "1000";
constant stEppDwrB : std_logic_vector(7 downto 0) := "0110" & "0001";
constant stEppDrdA : std_logic_vector(7 downto 0) := "0111" & "0010";
constant stEppDrdB : std_logic_vector(7 downto 0) := "1000" & "0011";
------------------------------------------------------------------------
-- Signal Declarations
------------------------------------------------------------------------
-- State machine current state register
signal stEppCur : std_logic_vector(7 downto 0) := stEppReady;
signal stEppNext : std_logic_vector(7 downto 0);
signal clkMain : std_logic;
-- Internal control signales
signal ctlEppWait : std_logic;
