9
Signal Name Pin Voltage Description
PMOD-JB-11 -- Gnd Ground
PMOD-JB-12 -- -- 3.3V Power
Table 10. Center PMOD FMC Connection
Rightmost PMOD connector (single)
Signal Name Pin Voltage Description
PMOD-JC-1 D18 2.5V I/O
PMOD-JC-2 D17 2.5V I/O
PMOD-JC-3 D15 2.5V I/O
PMOD-JC-4 C15 2.5V I/O
PMOD-JC-5 -- -- Ground
PMOD-JC-6 -- -- 3.3V Power
Table 11. Rightmost PMD FMC Connections
