D.A.S. Audio DASnet V1.5 - Manual (Page 42)

10. DEVICE VIEW WINDOWS - processors
DASnet has been designed to monitor and control parameters on the connected devices. There
are two types of devices, cabinets and processors.
The DSP window on DASnet has three main options: mixer, input EQ and ouput EQ:
mixer
input EQ
output EQ
Processors
DSP-2060A
DSP-4080
10.1 On the Mixer menu three options are available: Source, limiters and Linking.
Source is the input matrix and can be used for routing inputs and outputs.
In this case output 1 of the processor uses
inputs A and B, outputs2&3 use input A and
outputs 4&5&6 use input B.
Besides the input / output routing on the
Source menu the user can invert the
polarity of the output channel (phase)
Mute / Gain per output is available as well.
The delay per output is also accessible
from the Source menu.
DASnet - 42
