18 Troubleshooting
3.1. Resolving Installation Problems
If installation fails or you are trying to resolve a problem, you should try the
following before calling the Comtrol technical support line:
•
Check the signals between your peripherals and the interface box to verify
that they match (if applicable). See the appropriate Hardware Reference
Card for information.
• Check to make sure the serial and interface cables are connected properly.
• Check to see if the DIP switch is set to the desired address by checking the
/ROCKET/INSTALL.LOG file with an editor against the settings on each
controller.
• Reseat the controller in the slot.
• Make sure that the expansion slot screw was replaced after inserting the
controller.
• Reinstall the API , selecting a different I/O address range for the controller.
For possible I/O address conflicts, see Tables 3-1 and 3-2.
Table 3-1 defines the 64-byte I/O address blocks from 0 through 3FFh and their
known uses. Table 3-2 defines the 64-byte I/O address blocks from 400 through
FFFh and their known uses.
Table 3-1. System I/O Addresses – Up to 3FF
Address
Block
Addresses
Used
Description
000 – 03F Reserved for Motherboard
040 – 07F Reserved for Motherboard
080 – 0BF Reserved for Motherboard
0C0 – 0FF Reserved for Motherboard
100 – 13F
140 – 17F
180 – 1BF
1C0 – 1FF 1F0 – 1F8 Fixed Disk
200 – 23F
240 – 27F 278 – 27F
LPT2, IDE controllers,
multifunction boards (game
ports)
280 – 2BF
2C0 – 2FF
2E8 – 2EF
2F8 – 2FF COM4
COM2
300 – 33F
340 – 37F 378 – 37F LPT1
380 – 3BF 3B0 – 3BF Monochrome Display and LPT3
3C0 – 3FF
3D0 – 3DF
3E8 – 3EF
3F0 – 3F7
3F8 – 3FF Graphics Monitor Adapter
COM3
Floppy Disk Controller
COM1
Table 3-2. System I/O Address Aliases – Above 3FF
Address
Block
1st Alias 2nd Alias 3rd Alias
000 – 03F 400 – 43F 800 – 83F C00 – C3F
040 – 07F 440 – 47F 840 – 87F C40 – C7F
080 – 0BF 480 – 4BF 880 – 8BF C80 – CBF
0C0 – 0FF 4C0 – 4FF 8C0 – 8FF CC0 – CFF
100 – 13F 500 – 53F 900 – 93F D00 – D3F
140 – 17F 540 – 57F 940 – 97F D40 – D7F
180 – 1BF 580 – 5BF 980 – 9BF D80 – DBF
Table 3-1. System I/O Addresses – Up to 3FF(Continued)
Address
Block
Addresses
Used
Description
Section 3. Troubleshooting
