REMOTE CONTROL USING SMC-33
OR SMC-34
The optional SMC-33 or SMC-34 can be used to
remotely control the transceiver for added convenience.
The default assignments for the p J, [2], and [3] keys on
these options are the functions of the [VFO], [MR], and
[CALL] keys respectively on the transceiver {1: VFO,
2: MR, 3; CALL). These keys are referred to as PF
keys.
Use the default assignments without further change or, if
you prefer, customize the key functions using the
following procedure:
1 Make sure that Key Lock is turned OFF on the
transceiver.
2 On the option, press [1], [2], or [3]+ POWER ON.
Example: Press [1]+ POWER ON.
REMOTE CONTROL
Assignable functions are listed below:
APO
O C t
r r I
3 Press the transceiver key(s) for the function that you
wish to assign to the option key pressed in Step 2.
The assignment is completed. Repeat the same
procedure if you wish to assign different functions to the
other keys on the option.
Function Key Entry Function Key Entry
VFO select [VFO]
Tone Alert
ON/OFF
[F], [CALL]
Memory
recall
[MR] Squelch set [F], [MONI]
Call channel
recall
[CALL]
Frequency
step
[F], [T/CT]
Monitor
ON/OFF
[MONI]
Page
ON/OFF
[F], [1]
Frequency
select (UP)
ENC/SQL
clockwise
DTSS
ON/OFF
[H, [2]
Frequency
select
(OWN)
ENC/SQL
counterclockwise
DTMF
memory
read [F], [3]
Reverse
ON/OFF
[REV]
Lamp
ON/OFF
[LAMP]
Tone/CTCSS
ON/OFF
[T/CT]
Lamp latch
ON/OFF
[F], [LAMP]
Memory
transfer
[F], [VFO]
TX power
select
[F], [PTT]
Key Lock
ON/OFF
[F], [MR]
TX offset
direction
[F], [REV]
Note:
► Turn OFF the transceiver power before connecting the
option.
Locking the transceiver keys with Key Lock does not lock
the [1]. [2], and [3] keys on the options.
Option keys [1], [2], and [3J are not functional while
transmitting.
