Often a Tone frequency is required to access repeaters.
For example, 88.5 Hz may be needed in the U.S.A. or
Canada, and 1750 Hz is used in Europe. The Tone
frequencies listed below can be selected. On the
TH-22E/TH-42E, 1750 Hz also can be selected.
No.
Freq.
(Hz)
No.
Freq.
(Hz)
No.
Freq.
(Hz)
No.
Freq.
(Hz)
01
67.0
11
97.4
21
136.5
31
192.8
02
71.9
12
100.0
22
141.3
32
203.5
03
74.4
13
103.5
23
146.2
33
210.7
04
77.0
14
107.2
24
151.4
34
218.1
05
79.7
15
110.9
25
156.7
35
225.7
06
82.5
16
114.8
26
162.2
36
233.6
07
85.4
17
118.8
27
167.9
37
241.8
08
88.5
18
123.0
28
173.8
38
250.3
09
91.5
19
127.3
29
179.9
10
94.8
20
131.8
30
186.2
The following procedure allows you to select any of the
available tones.
1 Press [F] (1 s), [T/CT].
2 Turn the ENC/SQL control to select the desired Tone
frequency.
3 Press any key other than [MONI] or [LAMP] to store
the selected value.
AUTOPATCH
(U.S.A. and Canada Versions)
Some repeaters offer a service called Autopatch. This
feature allows you to dial a telephone number from your
transceiver and carry on a telephone conversation. This
repeater function cannot be used for commercial
transactions, but it can save lives when used
appropriately during emergencies.
Autopatch requires the use of a DTMF (Dual Tone Multi-
Frequency) keypad. The keypad includes the 12 keys
found on your telephone plus an additional 4 keys (A, B,
C, D). These additional keys are required for various
control operations by some repeater systems.
■ Activating the Keypad
1 Press and hold [PTT].
2 Press keys in sequence to transmit tones.
• To generate single-frequency tones for test
purposes, press [MONI] before pressing a single
key from [1] to [8].
31
