FLUKE 900 SERVICE MANUAL Selftest
#16 79.000 n 120.00 n 161.00 n IXuation - BitO
#17 199.00 n 240.00 n 281.00 n Duration - Bitl
#18 439.00 n 480.00 n 521.00 n Duration - Bit2
#19 919.00 n 960.00 n 1.0010 u Duration - Bit3
#20 1.8790 u 1.9200 u 1.9610 u Duration - Bit4
#21 3.7990 u 3.8400 u 3.8810 u Duration - Bit5
#22 7.6390 u 7.6800 u 7.7210 u Duration - Bit6
#23 15.319 u 15.360 u 15.401 u Duration - Bit7
#24 119.00 n 120.00 n 241.00 n Delay - BitO
#25 239.00 n 240.00 n 361.00 n Delay - Bitl
#26 479.00 n 480.00 n 601.00 n Delay - Bit2
#27 959.00 n 960.00 n 1.0810 u Delay - Bit3
#28 1.9190 u 1.9200 u 2.0410 u Delay - Bit4
#29 3.8390 u 3.8400 u 3.9610 u Delay - Bit5
#30 7.6790 u 7.6800 u 7.7610 u Delay - Bit6
#31 15.359 u 15.360 u 15.441 u Delay - Bit7
#32 79.000 n 120.00 n 201.00 n DGATE Inversion Test
#33 229.00 n 320.00 n 401.00 n DGATE Infinite Duration Test
TEST 52
PULL0_XTRIG
If the Simulation Option (900-001) is installed, this test verifies the operation of the trigger
circuit inside the shadow RAM ASIC chip configured for extended trigger. It walks a 0
through each line on the puU-ups latches and tries to trigger on each event
3 - 1 9
