Fluke 900 Parts Lists FLUKE 9003ERVICE MANUAL
A3 High Speed (cent.)
FLUKE
N
0
REFERENCE PART TOT T
DESIGNATORS---------- : ----------------- \ir\ QTY-
— T?
U65,U97,U167,U187 RN 8X1 KOHM DIP 16P 942008- ■ 4
U68 8 BIT DAC 941211 . 1
U69 OP AMP 941315 1
U77 IC 74HCT245 940762 1 1
U79,U99,U165,U190 IC 74F521 940804, 4
U80,U82,U83,U101,U104, TRANSISTOR 2N2369A 921242 8
U113,U125,U199 921242
U81,U98,U154,U191 IC 74ALS639 940817 4
U84 IC 74ALS654 940820 1
U85,U103,U115,U127-130, DIP RELAY 941810 18
U144,U146,U156,U157, 941810
U169,U171-176 941810
U105, GATE ARRAY 942131 2
U123 942131 1
U114, U126,U170 IC 7407 HEX BUFFER 940619 3
U142 64Kxl SRAM 941802 1 1
U143 IC 26LS31 940544 1
U145 28 PIN BLK ZIF SOCKT 942149 1
XU49,XU77 20 PIN SOCKET 942094 2
XU53,XU142 24 PIN N. SOCKET 942099 2
XU105,XU123 84 PIN PLCC SOCKET 942078 2
XU14 5 ZIP ADAPTOR 942144 1
CALIBRATION COMPONENTS CAP l.OpF 921197 3
CAP 1.5pF 921200 3
CAP 1.8pF 921205 3
CAP 2.2pF 921213 3
CAP 3.3pF 921218 3
CAP 4.0pF 921221 3
CAP 6.8pF 921226 3
RES 47K 921192
RES 57K 921189 3
RES 86K 921184 3
RES 113K 921176 3
RES 150K 921171 3
RES 365K 921168 3
NOTES:
1 = Optional: part of -001 Simulation option
2 = Selected parts: aU seven 74ALS09 must be the same color code (speed).
Use 921234 for orange dot (group B), 921239 for green dot (group C).
3 = Calibration resistors and capacitors are used in the procedure outlined in Section 5.4.2.5
7 -10
