Crestron Isys ® TPS-12B/W, TPS-15B/W & TPS-17B/W Tilt Touchpanels
QuickMedia™
The TPS-12B/W, TPS-15B/W & TPS-17B/W are also equipped with a single
QuickMedia input port. Through QuickMedia (QM), the TPS-12B/W, TPS-15B/W
& TPS-17B/W interface directly with Crestron’s QM-based MediaManager products
using a single CAT5e type cable. Over wiring distances of up to 300 feet, the QM
input port accepts video signals from composite, S-video and standard definition
component sources along with discrete audio signals from one stereo program source
and up to two microphones. For more information on QM applications, refer to the
latest revision of the Crestron MediaManager Applications Guide (Doc. 6244) which
is available from the Crestron website (
http://www.crestron.com/manuals ).
NOTE: The TPS-12B/W, TPS-15B/W & TPS-17B/W do not support RGB.
High-Speed Connectivity
Both Cresnet and high-speed Ethernet are standard on the TPS-12B/W, TPS-15B/W
& TPS-17B/W, providing for easy network integration and seamless
communications with Crestron control systems. In addition, a USB port is provided
for future applications. The "RS-232 Port for Touch Output" operation transmits
touch coordinates to external devices via RS-232 for “Touch-The-PC” and other
functions.
Cresnet ®
Cresnet is the communications backbone for many Crestron touchpanels, keypads,
lighting controls and other devices. The Cresnet bus is a simple, yet flexible 4-wire
network that provides rock-solid bidirectional communication and power for up to
252 Cresnet devices.
Memory
The TPS-12B/W, TPS-15B/W & TPS-17B/W touchpanels feature 128 MB DDR
RAM and 32 MB Flash, with a built-in Compact Flash slot that allows flash memory
expansion up to 160 MB.
Slimline Tiltcase Design
The stylish tiltcase housing allows smooth tilt adjustment from 45 to 90 degrees and
features an integral cable strain relief and rear cover to secure and hide the
connections at the back of the touchpanel. Four backlit pushbuttons are also
provided, allowing for quick access to commonly used functions.
Operations Guide – DOC. 6464A Tilt Touchpanels: TPS-12B/W, TPS-15B/W & TPS-17B/W • 3
