Crestron Isys
®
TPS-12B/W, TPS-15B/W & TPS-17B/W Tilt
Touchpanels
RS-232 Menu
The touchpanel allows for one of four RS-232 communication modes:
•
Console (i.e. loading projects and firmware)
•
Touch Output (communication of touch coordinates to an external device)
•
Mouse Input (allows a mouse to control the touchpanel)
•
External Touch Input (allows another device to control the touchpanel)
For convenience the RS-232 MENU also permits the selection of the RS-232
communication options Baud Rate, Data Bits, Stop Bits, Parity, RTS On/Off and
XON-XOFF On/Off.
Touch the communication option to select communication parameters and then select
Save and Return to save the RS-232 settings and return to the SETUP MENU.
Default settings: Console mode, Baud Rate: 115200, data bits: 8, stop bits: 1,
parity: none, RTS off and XON/XOFF off.
RS-232 MENU
Operations Guide – DOC. 6464A
Tilt Touchpanels: TPS-12B/W, TPS-15B/W & TPS-17B/W
• 27
