Crestron Isys ® TPS-12B/W, TPS-15B/W & TPS-17B/W Tilt Touchpanels
TPS-15B/W & TPS-17B/W Overall Dimensions (Side View at Maximum and Minimum Elevation)
45°
11.61 in
(29.49 cm)
12.40 in
(31.50 cm)
13.47 in
(34.21 cm)
NOTE: All three touchpanels share an identical base unit.
Bottom View
7.00 in
(17.78 cm)
9.60 in
(24.38 cm)
8.40 in
(21.34 cm)
Operations Guide – DOC. 6464A Tilt Touchpanels: TPS-12B/W, TPS-15B/W & TPS-17B/W • 11
