Tilt Touchpanels Crestron Isys ® TPS-12B/W, TPS-15B/W & TPS-17B/W
Access to I/O Panel and Cable Routing
Remove four screws to access
the I/O Panel
Route cables through here
The TPS-12B/W, TPS-15B/W & TPS-17B/W touchpanels have rubber pads on the
underside of the base so they can rest on a horizontal surface. Make the required
connections as shown and described in the following sections. Refer to the
illustration on the following page for proper connections; apply power last.
36 • Tilt Touchpanels: TPS-12B/W, TPS-15B/W & TPS-17B/W Operations Guide – DOC. 6464A
