Pin No. Name I/O Function
41 VDD - +5V power supply pin
42 DACCKOUT 0 DAC system clock output pin
43 ENCCKOUT 0 CD decoder system clock output pin
44 CDDATA 1 CD decoder data input pin
45 CDBCK 1 CD decoder bit clock Input pin
46 CDLRCK I CD decoder LR clock input pin
47 CDTX 1 Pin for inputting signal from CD decoder output
48 DITOUT 0 Bi-phase modulation output pin
49 TP6 1 For tests
50 XRESET 1 System reset input pin. L: Reset
51 TP7 1 For tests
52 XCAS 0 DRAM row address strobe signal output pin
53 XOE 0 DRAM output enable signal output pin
54 A8 o
DRAM address output pin
55 A7 0
56 A6 0
57 A5 0
58 A4 o
59 A3 0
60 A2 0
61 VDD - +5V power supply pin
62 VSS - Ground pin
63 A1 0
DRAM address output pin 64 AO 0
65 A9 0
66 XRAS 0 DRAM column address strobe signal output pin
67 XWR o DRAM read/write signal output pin
68 DQ2 I/O
DRAM data input/output pin
69 DQ1 I/O
70 DQ4 I/O
71 DQ3 I/O
72 TPO 1
For tests
73 TP1 1
74 TP2 1
75 TP3 0
76 ENCVCOIN 1 Encode circuit clock input pin
77 ENCLPFO 0 LPF output pin
78 ENCLPFI 1 LPF input pin
79 ENCPCO 0 Phase comparator output pin
80 ENCERR 0 Lock state monitor signal output pin. H : Unlocked. L: Locked
