PDR-04
Mark No. Description Part No. Mark No.
R2 RS1/16S104J
R135 RS1/16S132J
R6 RSI/168133J
R1106 RS1/16S202J
Rn05 RS1/16S222J
R134 RS1/16S362J
R12 RS1/16S471J
R8 RS1/16S472J
VRIO (2.2ka) RCP1019
VR1, VR103-VR105, VRl 07 (1 Oka) RCPl 045
VR108,VR112,VR115 (lOkn) RCPl 045
VRl06, VRl11 (22kn) RCPl046
VRl 10, VRl 19 (47ka) RCPl 047
Other Resistors RSl/lOSOODJ
OTHERS
CN106 2H CONNECTOR lOP SIOB-ZR
CN105 ZH CONNECTOR 13P S13B-ZR
CN107 KR CONNECTOR S6B-PH-K-S
PCB BINDER VEF1008
I SERVO UCOM BOARD ASSY
SEMICONDUCTORS
Description Part No.
IC5008
IC201
IC206
IC204,IC5024
IC353
IC352
A IC208
IC205
IC351
IC356
IC207
IC311
IC361
IC357,IC358
IC354
IC355, 1C359, 1C362
IC363
IC360
Q203
Q202
Q14
Q201
013,0280
0208
05026
D353
D354
D206
D1351
D210
D202,D205
CAPACITORS
C291
C1308,C284,C295
C247-C257
C355,C356
C282
BA4560F
CXA13720
CXD2500B0
HD74HC4053FP
HD74HC573FP
LH5116NA-10
LM2940CT-5.0
PA9004A
PD4785A
PD4786A
PDJ006A
PST529C
PST572E
TC74HC367AF
TC7S00F
TC7S04F
TC7S14F
PYY1196
2SA1037K
2SC2412K
DTA124EK
DTA124ES
DTC114TK
DTC114TS
DTC124ES
1SS133X
DAI 14
DA204K
DAN202K
DAP202K
MTZJ3.9BX
CCS0CH100D50
CCS0CH101J50
CCS0CH121J50
CCSOCH150J50
CCSRCH101J50
Cl 2 CCSRCH270J50
C241 CEAS100M50
C209,C212,C290 CEAS101M6R3
C278 CEAS1R0M50
Cl 302,C264,C271 CEAS2R2M50
C205,C235-C238, C293,C5016 CEAS470M10
C5018 CEAS470M10
C240 CEAS471M10
C351,C358 CEAS471M6R3
C203,C207 CEAS4R7M50
C288 CEASR47M50
Cl 8 CKS0YB102K50
Cl 310, C201, C202, C204, C206 CKSOYBl04K25
C274 CKSOYBl04K25
C5004 CKS0YB222K50
Cl 309 CKS0YB272K50
C5013 CKS0YB333K50
Cl 304 CKS0YB471K50
C260 CKS0YB683K25
C233,C234,C239, C242, C280 CKSOYFl03Z50
C5017,C5019 CKSOYFl03Z50
Cl 301,Cl 307,C285, C292, C352 CKSOYFl04Z25
C357 CKSOYFl04Z25
C283 CKS0YF473Z50
C279 CKSRYB102K50
C208,C210,C213, C218,C289 CKSRYBl03K50
C287 CKSRYBl52K50
C258 CKSRYB223K25
C267-C270 CKSRYB331K50
C219,C262 CKSRYB332K50
C211,C217 CKSRYB333K16
C5005-C5008 CKSRYB471K50
C214,C215 CKSRYB472K50
C216,C261,C286 CKSRYB473K16
C259 CKSRYB681K50
Cl202, C353,C354, C360, C370 CKSRYFl03Z50
Cl 305, Cl 306, C359 CKSRYFl04Z25
C281 CKSRYF473Z25
C272,C273 C0MA104J50
C361 (0.22F,5.5V) PCH1131
C263, C275-C277 (0.33^iF, 16V) PCLl 043
C5002,C5011 (0.15^F,16V) PCLl044
C1201 (0.082iiF,16V) PCL1045
C243 (0.1 jli F,16V) PCLl 046
RESISTORS
R1, R1212, R1214, R297,R32 RSI/16S0R0J
R1381-R1388,R280 RSI/16S1OIJ
R233,R5007 RS1/16S102J
R1215,R1308,R213,R214,R216 RSI/16S103J
R247, R248,R256-R259,R266 RS1/16S103J
R268,R5006 RS1/16S103J
R251, R260,R267 RSI/16S104J
R206,R241 RS1/16S105J
R253,R254 RS1/16S114J
R353-R361 RS1/16S124J
R208,R232 RS1/16S133J
R281 RS1/16S181J
R201 RS1/16S184J
R210 RS1/16S204J
R5022 RS1/16S221J
