d) Seek Track 0

Carriage is moved to TOC area (Home position).

PDR-04

Determined according to TOCP state when it starts to move

Signal

TOCP (IN)

Command

Starts to move ©

Moves inside

Program area

Starts to move ®

Move outside

TOC area

4 i

Limit 3.4s

23 : Tracking OFF Slider REV

Limit 300ms

22 : Tracking OFF Slider FWD

© Focus ON

Auto focus starts

Move at low
speed inside

Program area

STOP

TOC area

Limit

500ms

23 : Tracking OFF Slider REV

30 : Slider-low speed instruction

20 : Tracking and Slider OFF
33 : Slider-high speed instruction
