PDR-04
Parts List
Mark No. Description Part No. Mark No. Description Part No.
NSP 1 STRATEGY SMALL BOARD ASSY PWX1518
NSP 2 SERVO UCOM BOARD ASSY PWZ3387
NSP 3 AUDIO DIGITAL BOARD ASSY PWZ3388
NSP 4 ALC BOARD ASSY PWZ3389
NSP 5
e
HEADPHONE BOARD ASSY PWZ3390
O
7 FUNCTION BOARD ASSY PWZ3042
8 POWER A BOARD ASSY PWZ3354
9 POWER B BOARD ASSY PWZ3359
A 10 Strain Relief CM-22C
11 39P F.F.C/30V PDD1181
12 Connector Assy (5P) PF05PP-D37
A
13 AC Power Cord PDG1015
14 Ferrite Core PTH1018
A 15 Power Transformer
(Servo, AC120V) PTT1308
A 16 Power Transformer
(Audio, AC120V) PTT1309
A 17 Fuse(FU11,1A) REK1075
18 Screw ABA1207
19 Cord Clamper RNH-184
NSP 20 Cushion (3.5) PEB1110
NSP 21 Spacer A PEB1228
22 Rubber Spacer A PEB1280
23 Rubber Spacer B PEB1281
NSP 24 Under Base PNA2195
25 Audio Angle PNA2197
26 Rear Base PNA2314
27 Earth Plate PBK1090
28 Insulator PNW1912
NSP 29 PCB Holder PNW2100
30 PCB Holder PNW2562
NSP 31 PCB Spacer PNY-404
NSP 32 Loading Mechanism Assy TT PXA1568
33 Headphone Knob PAC1600
34 Operation Button 78 PAC1744
35 REC Button PAC1804
NSP
36 Power Button PAG 1805
37 Cord Clamper DNF1128
38 Display Window PAM 1668
39 FL Sheet PAM 1673
40 Front Panel PAN1349
41 Tray Panel PNW2701
42 Display Panel 7 PNW2662
43 LED Lens PNW2019
44 REC Ring PNW2558
45 REC Lens PNW2559
46 Holder PNW2591
47 Tray Holder PNW2592
48 Control Panel PNW2703
49 Name Plate VAM1032
50 65 Label ORW1069
51
52 Indicator Lens
PEA1206
53 Bonnet PYY1175
54 Screw BBT30P080FCC
55 Ferrite Core PTH 1009
56 Screw BBZ30P080FCC
57 Screw IBZ30P060FCC
58 Screw IBZ30P080FCC
59 Screw IBZ30P150FCC
60 Screw PPZ30P150FMC
61 Rivet RBM-003
62 Black Label PRW1470
63 Screw FBT40P080FZK
64 Disc Guard PNM1245
65 Shield Sheet PNM1308
66 1C PYY1196
67 Earth Lead Unit PDF1154
68 Binder Holder PNW1021
