PDR-04
5. PCB PARTS LIST
NOTES: • Parts marked by *NSP" are generally unavailable because they are not in our Master Spare Parts List.
• The ^ mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
• When ordering resistors, first convert resistance values into codeform as shown in the following examples.
Ex.l When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J-5%,
andK=:10%).
560 n 56x10' 561 ................ ............................................ RD1/4PU [Hll]|I] 7
47kD. -► 47x10' -► 473 ................................................................................................................................................................ RD1/4PU\À]\7]{^J
0.5 a -► R50 ........................................................................................./?
a
^2
h
1II[I1!II
a
:
la
-►
iRO
..............................................................................
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Q -► 562x10' 5621 ......................................................... RN1/4PCMEM\1\F
Mark No. Description Part No. Mark No.
LIST OF ASSEMBLIES
NSP MOTHER BOARD ASSY PYY1209
HEAD BOARD ASSY PYY1211
NSP h HEAD BOARD ASSY PWZ3386
NSP - ALC BOARD ASSY PWZ3389
NSP - HEADPHONE BOARD ASSY PWZ3390
NSP L m echanism BOARD ASSY PWZ3391
-AUDIO DIGITAL BOARD ASSY PYY1212
NSP au D 10 DIGITAL BOARD ASSY PWZ3388
LSERVO UCOM BOARD ASSY PYY1214
NSP •- SERVO UCOM BOARD ASSY PWZ3387
NSP STRATEGY SMALL BOARD ASSY PWX1518
NSP SUB BOARD ASSY PWX1505
-FUNCTION BOARD ASSY PWZ3042
- POWER A BOARD ASSY PWZ3354
L POWER B BOARD ASSY PWZ3359
MOTHER BOARD ASSY
OTHERS
PC BOARD PNP1418
Description Part No.
0103-0106 2SA1037K
0107,0108 2SA1461
0102 2SB1189
0101 2SC2412K
QUO 2SJ146
0115 DTA114EK
0111 DTA114TK
0117 DTA124EK
0116 DTC114TK
0109 DTC114TS
0113 DTC144TS
D101 DAI 14
DUO UDZ6.2B
CAPACITORS
Cl03, Cl42, Cl 45, Cl46 CCSQCH100D50
Cl23,Cl 24 CCSQCH221J50
C109-C112 CCSQCH391J50
Cl47, Cl 48 CCSQCH471J50
Cl 22 CCSQCH620J50
Cl 40 CCSQCK2R0C50
C105-C108 CCSQSL821J50
Cl 16 CEJA100M16
Cl 01, Cl 02, Cl 13, Cl 21, Cl 25 CEJAl 01 Ml 0
C221,C224, C227, C230 CEJA470M16
MECHANISM BOARD ASSY
SEMICONDUCTORS
D1001
PCI 001
RESISTORS
All Resistors
OTHERS
J1002 CONNECTOR ASSY 7P
! HEAD BOARD ASSY
SEMICONDUCTORS
A
A
I Cl 02,I Cl 04
IC202
IC203
ICIOI
I Cl 03
GP1S24
NX5803K-F1
Rsi/iosnnnj
PDE1260
BA4560F
LA6517
LA6520
PA4022A
TC7S08F
Cl 17 CEJANP1R0M50
Cl 27 CEJANP4R7M16
Cl 33 CRXA103J50
Cl 14, Cl 30, Cl 31, Cl 37, Cl 38 CKSQYBl 03K50
C141 CKSQYB103K50
Cl 28 CKSQYBl82K50
Cn CKSQYB683K25
Cl04, Cl 18, Cl 20, Cl26 CKSQYF103Z50
Cl 34, Cl 35, Cl 39, Cl 64, Cl 89 CKSQYF103Z50
C220,C222, C223, C225,C226 CKSQYF103Z50
C228,C229,C232 CKSQYF103Z50
Cl15,Cl 32,Cl 87 CKSQYFl04Z25
C9 CKSRYB392K50
Cl 44 CKSRYF103Z50
RESISTORS
R130 (62n) PCN1037
R148 (2.2kD) PCN1038
R1104 (2.2ka) PCN1039
R138,R162 RN1/10SE1202D
R136,R161 RN1/10SE3002D
