Kenmore 106.511800 - Manual (Page 17)

NOTE: To exit without saving changes, press WATER/ICE at
any time while in adjust mode, or allow about 60 seconds of
inactivity and adjust mode will turn off automatically.
When adjusting temperature set points, use the following chart
as a guide.
CONDITION: TEMPERATURE
ADJUSTMENT:
REFRIGERATOR too cold REFRIGERATOR Setting
1° higher
REFRIGERATOR too warm REFRIGERATOR Setting
1° lower
FREEZER too cold FREEZER Setting
1° higher
FREEZER too warm /
Too little ice
FREEZER Setting
1° lower
The set point range for the refrigerator is 33°F to 45°F (0°C to
7°C). The set point range for the freezer is -5°F to 5°F (-21 °C to
-15°C).
Cooling On/Off
Your refrigerator and freezer will not cool when cooling is
turned off.
■ To turn cooling off, press and hold the LOCK and
MEASURED FILL buttons at the same time for 3 seconds.
IMPORTANT: To avoid unintentionally locking the dispenser
or changing other settings, be sure to press both buttons at
exactly the same time.
When cooling is off, “COOLING OFF” will appear on the
display screen.
■ Press and hold LOCK and MEASURED FILL for 3 seconds
again to turn cooling back on.
Additional Features
Accelerated Ice Production
The Accelerated Ice feature assists with temporary periods of
heavy ice usage by increasing ice production.
IMPORTANT: This feature only works if the ice maker is turned
on. See “Ice Maker and Storage Bin.”
■ To turn on the feature, press SETTINGS then TEMPERATURE.
When the feature is on, the Accelerated Ice icon will
appear on the dispenser display screen.
Acceler
aa Ice
The Accelerated Ice setting will remain on for a minimum of
90 minutes unless manually turned off.
■ To manually turn off the feature, press SETTINGS then
TEMPERATURE again, or adjust the freezer temperature set
point. The Accelerated Ice icon will disappear when the
feature is off.
NOTE: If increased ice production is desired at all times,
change the freezer set point to a lower setting. Setting the
freezer to a colder temperature may make some foods, such as
ice cream, harder.
Door Ajar Alarm
The Door Ajar Alarm feature sounds an alarm when the
refrigerator or freezer door is open for 5 minutes and the
product cooling is turned on. The alarm will repeat every
2 minutes. Close both doors to turn it off. The feature then resets
and will reactivate when either door is left open again for
5 minutes.
NOTE: To mute the audible alarm while keeping the doors open,
such as while cleaning the inside of the refrigerator, press any
button on the control panel. The alarm sound will be temporarily
turned off, but the Door Ajar icon will still be displayed on the
dispenser control panel.
Disabling Sounds
■ To turn off all dispenser and control sounds, press and hold
WATER/ICE and MEASURED FILL at the same time for
3 seconds.
IMPORTANT: To avoid unintentionally changing other
settings, be sure to press both buttons at exactly the same
time.
■ To turn all sounds back on, press and hold WATER/ICE and
MEASURED FILL at the same time for 3 seconds again.
IMPORTANT: After connecting the refrigerator to a water source
or replacing the water filter, flush the water system. Use a sturdy
container to depress and hold the water dispenser pad for
5 seconds, then release it for 5 seconds. Repeat until water
begins to flow. Once water begins to flow, continue depressing
and releasing the dispenser pad (5 seconds on, 5 seconds off)
until a total of 3 gal. (12 L) has been dispensed. This will flush air
from the filter and water dispensing system, and prepare the
water filter for use. Additional flushing may be required in some
households. As air is cleared from the system, water may spurt
out of the dispenser.
NOTES:
■ The dispensing system will not operate when the freezer
door is open.
■ Allow 24 hours for the refrigerator to cool down and chill
water.
■ Allow 24 hours to produce the first batch of ice. Discard the
first three batches of ice produced. Wait 72 hours for full
ice production.
■ The display screen on the dispenser control panel will turn
off automatically and enter “sleep” mode when the control
buttons and dispenser pad have not been used for 2 minutes
or more. While in “sleep” mode, the first press of a control
button will only reactivate the display screen, without
changing any settings. After reactivation, changes to any
settings can then be made. If no changes are made within
2 minutes, the display will re-enter “sleep” mode.
17
