2 .
3.
Style 3
1. Unplug refrigerator or disconnect power.
Remove and discard the block nylon plug from the gray
water tube on the rear of the refrigerator.
If the gray water tube supplied with the refrigerator is not
long enough, o 1A" x W (6.35 mm x 6.35 mm) coupling is
needed in order to connect the water tubing to on existing
household water line. Thread the provided nut onto the
coupling on the end of the copper tubing.
NOTE: Tighten the nut by hand. Then tighten it with o
wrench two more turns. Do not overtighten.
A. Refrigerator water tubing E. Ferruie (purchased}
B. Nut (provided) F. Nut (purchased)
C. Buib G. Househoid water iine
D. Coupiing (purchased)
4. Turn shutoff valve ON.
5. Check for leaks. Tighten any nuts or connections (including
connections at the valve) that leak.
Complete the Installation
^WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
1. Plug into o grounded 3 prong outlet.
2. Flush the water system. See “Prepare the Water System” or
“Water and Ice Dispensers.”
NOTE: Allow 24 hours to produce the first botch of ice. Allow
3 days to completely fill ice container.
On some models, your refrigerator's accessory packet includes
on air filter, which must be installed prior to use. On some
models, the air filter is already installed at the factory.
The air filter reduces the buildup of odors. This helps to maintain
o cleaner environment inside the refrigerator.
Installing the Air Fiiter (on some modeis)
The filter should be installed behind the vented door, which is
located (depending on your model) along either the rear or left
interior wall near the top of the refrigerator compartment.
1. Remove the air filter from its packaging.
2. Lift open the vented door.
3. Snap the filter into place.
Installing the Fiiter Status Indicator (on some modeis)
The filter comes with o status indicator, which should be
activated and installed at the some time the air filter is installed.
REPLACE
▼ i
1. Place the indicator face-down on o firm, flat surface.
2. Apply pressure to the bubble on the bock of the indicator,
until the bubble pops to activate the indicator.
3. Lift open the vented air filter door. There ore notches behind
the door. Slide the indicator down into the notches, facing
outward.
