Braeburn 1025NC - Manual (Page 7)

7
4 System Testing
Warning
Read Before Testing
• Do not short (or jumper) across terminals on the gas valve or at the
system control board to test the thermostat installation. This could
damage the thermostat and void the warranty.
1 Move the SYSTEM switch to ON mode.
2 Press to raise the set temperature a minimum of 3 degrees above
the current room temperature. The system should start within a few
seconds. With a gas heating system, the fan may not start right away.
3 Move the
SYSTEM switch to the OFF mode. Allow the heating system to
fully shut down.
4 Move the
FAN switch to the ON mode. The system fan should start (on
systems where a fan is installed) within a few seconds.
5 Move the
FAN switch to the AUTO mode. Allow the system fan to
turn off.
5 Setting User Options
Advanced User Options
User options allow you to customize some of your thermostats features.
The default user options are compatible with most applications, therefore it
is not required that you adjust them.
To access the User Options menu, hold down both the and buttons
for approximately 3 seconds until the screen changes and displays
the User Option.
Press the or button to change the setting for the displayed User Option.
After you have made your desired setting, press and together to
return to the normal mode.
The thermostat will also return to normal mode after your last user option
is made or after no keys have been pressed for 15 seconds.
