Connect your wires, Conventional systems – Braeburn 1025NC User Manual
Page 4
4
Terminal Function Description
R
Input
Power Connection (24 Volt AC Heating
Transformer or Millivolt Power Source)
G
Output
Fan Control
W1
Output
Conventional Heat Control
V3
Output
Zone Valve Power Close
C
Input
24 Volt AC Transformer Common
Connect Your Wires
3
Wiring Terminations
Heat Only or Millivolt
R Power Connection
W1 Heat Relay
G Fan Control [note 3]
C 24 Volt AC Transformer Common [note 2]
Typical Wiring Configurations
Conventional Systems
