Braeburn 1025NC User Manual
1025nc, Detailed user guide, Single stage heat only

This thermostat requires 24 Volt AC Power or two (2) properly installed
“AA” Alkaline batteries for proper operation. When connecting 24 Volt
AC Power the batteries may be installed as a backup.
For use only as described in this manual. Any other use
will void warranty.
1025NC
Single Stage Heat Only
1
Specifications
2 About Your Thermostat
3 Installation
4 System Testing
5 Setting User Options
6 Operating Your Thermostat
7 Thermostat Maintenance
®
Warning
Turn off power to the heating equipment
before installation.
Attention
For installation by experienced service
technicians only.
Read all instructions before proceeding.
This thermostat is compatible with:
• Single stage heat only systems
• 250 – 750 millivolt heat only systems
• 2 or 3 wire hydronic zone systems
Electrical and control specifications:
• Electrical Rating: 24 Volt AC
• 1 amp maximum load per terminal
• AC Power: 18 – 30 Volts AC
• DC Power: 3.0 Volt DC (2 “AA” Alkaline Batteries Included)
• Control Range: 45° – 90° F (7° – 32° C)
• Temperature Accuracy: +/- 1° F (+/- .5° C)
Terminations
• 1025NC – R, G, W1, V3, C
1 Specifications
1025NCW-100-03
Non-Programmable
Thermostat
Model number is located on back
of thermostat
Detailed
User Guide
