4
Status After CLEAR–Factory Default Settings
At initial power up or after Installer CLEAR is pressed, the thermostat is
reset to factory defaults. Installer CLEAR is located on the circuit board.
5
cont.
Programming Installer Settings
4
Function Status After CLEAR
Operation mode OFF, Auto Changeover enabled
Temperature hold Permanent and temporary hold cleared
Fan Switch AUTO
Clock 12:00 pm, Monday
Room temperature Display 70° F (21.0° C), to be renewed within
5 seconds
Set point temperature 62° F (17.0° C) for Heat and Emergency Heat
83° F (28.0° C) for Cool
Temperature scale Fahrenheit
Operating program DAY program, Monday
Low-battery warning Off, to be renewed within 5 seconds
AC interrupted warning Off, to be renewed within 5 seconds
1st stage differential 0.2° F (0.1° C)
2nd stage differential 2° F (1.0° C)
3rd stage differential 2° F (1.0° C)
Programming 7 Day, 4 Event
Deadband 3° F
Residual Cooling Fan Delay 60 seconds
Short cycle protection timer On, 5 minutes, Reset
Adaptive Recovery Mode OFF
Output relays All turned off
Recirculating Fan Timer reset, with 24 min OFF, 12 min ON, Lock OFF
Extended Hold Long (indefinite)
Filter Check Monitor 0 days-No Warning, Timer reset
Keypad Lock Complete (level 2)
System type Conventional, Single Stage
1st Stage Heat Fan Control Gas
2nd Stage Heat Fan Control Electric
Fossil Fuel Compressor Lock Off
Auto Changeover Enabled
Compressor Outage Protection Off, Timer reset
Temperature Sensor
Internal
12 / 24 Hour Clock 12 hour
Adjustment Limit from Set Point 0, OFF
AC Interrupt Warning Mode
OFF
User Profile Residential
Compressor Balance Point 0 deg – No Lockout
Programming Installer Settings
4
Function Status After CLEAR
Auxiliary Balance Point 0 deg – No Lockout
Economizer Control None – Disabled
UV Monitor 0 days – No Warning, Timer reset
Humidifier Pad Monitor 0 days – No Warning, Timer reset
Heat Limit 90 deg – No Limit
Cool Limit 45 deg – No Limit
Maximum Override Duration 4 hours
Status After CLEAR–Factory Default Settings (continued)
When the User RESET button is pressed, the following options will reset to the
factory defaults. All other settings are saved when the RESET button is pressed.
Function Status After RESET
Programming Default setting depending on programming mode
setting (see User Manual). For manual mode:
Heat - 62° F, Cool - 83° F.
Clock 12:00 pm, Monday
1st stage differential 0.2° F (0.1° C)
2nd stage differential 2° F (1.0° C)
3rd stage differential 2° F (1.0° C)
Filter, UV and Humidity Pad
Check Monitor
0 days-No Warning, Timer reset
Adjustment Limit from Set Point 0, OFF
Temperature Hold
Permanent and temporary hold cleared,
reset to Long Hold
Short Cycle Timer Reset
Recirculating Fan Timer reset, 24 minute off cycle. With recirculating
lock set, fan state defaults to CIRC.
Maximum Temporary Override
Duration
4 hours
Status After RESET–Factory Default Settings
