5. Brightness sensor
6. Power supply plug
7. Audio video input
8. Serial port for external GPS receiver
9. Serial port for TMC receiver
10. Speaker
11. USB port
1.4 Keyboard
• SPEAK: repeats the last vocal instruction
and opens the volume control window
• MENU: opens the main menus available
• FIND: opens find window to search for
addresses, marks, POI
• ESC: exits from the current menu and
switches into cursor mode or GPS mode
• JOYSTICK:
Upper arrow: moves the cursor up
Lower arrow: moves the cursor down
Right arrow: moves the cursor right
Left arrow: moves the cursor left
• ENT: confirm a choice or selection, opens
the function menu
• + zooms in the map
• - zooms out the map
• INFO: opens the full info window
• MODE: switches among the different
viewing options for map, instruction and
trip computer pages
• PAGE: switches among the available pages:
map, instructions and the trip computer
• POWER: powers on and off the unit. Opens
the brightness control window.
1
2
3
4
front view
side view
5
6 7
9
8
10
11
