1.3 Hardware features
Looking at the navigator you can see the
following components:
1. Keyboard
2. 5” LCD TFT display
3. Infrared sensor
4. Slot for Secure Digital memory cards
5. Audio output
6. Brightness sensor
7. Power supply plug
8. Audio video input
9. Serial port for external GPS antenna
10. Serial port for TMC receiver
11. Speaker
12. USB port
1.4 Keyboard
• MENU: opens the main menus available
• FIND: opens find window to search for
addresses, marks, POI
• ESC: exits from the current menu and
switches into cursor mode or GPS mode
• JOYSTICK:
Upper arrow: moves the cursor up
Lower arrow: moves the cursor down
Right arrow: moves the cursor right
Left arrow: moves the cursor left
ENTER Function
The enter function is obtained pressing the
Centre of the JOYSTICK. When you are in a
menu this function is performed by the +
button
• + zooms in the map, ENTER function
• - zooms out the map
• PAGE: selects the different views for
the map, the instructions and the trip
computer
1
2
3
5
4
front view
side view
6
7 8
9
10
11
12
