29
11.0 YX Matrix System Technical Parameters
Model
Technical Parameters
YX-1044
Video
Enhancement 0dB
Max. Transmission Delay
10nS(±1nS)
Switching Speed 40nS(Longest Time)
Signal Type Component/Composite Video
Video Input Connector 4 Set RCA Female Connectors
Video Input Impedance 75Ω
Video Output Connector 4 Set RCA Female Connectors
Video Output Impedance 75Ω
Audio
Input/Output Connector RCA Female Connectors
Signal Type Stereo, Balanced or Unbalanced, Digital Optical Audio
Specifications
Power Adaptor DC 12V
Operating Temperature 0 ~+85 ℃ ℃
Housing Measurements 440(L)x185(W)x43mm(H)
Product Weight 2200g
Median Failure Interval 30,000 Hours
12.0 Common Problems and Solutions
1. What to do if the YX matrix front panel keys switching not responsive?
Answer: The YX matrix front panel keys employ scanning testing and require longer response
time. Press the keys for 2 seconds and then release. This way, key switching will be
responsive in operation.
2. What to do if matrix does not display or color display is abnormal after hot plug?
Answer: Switching of the matrix system goes through the IC chips. If the voltage difference
between the input signal equipment and the matrix equipment is too large, hot plug
could easily cause damage to the IC chips. Please turn off power to the system before
plugging or unplugging.
3. What to do if ghosting happens when YPbPr signals output to display?
Answer: Ghosting is often caused either by the projector, inferior cable quality or long
transmission distance. You are advised to adjust the projector or replace with better
quality cable.
4. What to do if loss of color reproduction happens or no video signal output?
