28
Example 4: “STO” and “RCL” functions.
Key LCD Display Operation
OUT
IN
1 2 3 4
1 2 3 4
1. Press the NO.2 key of the
output channel, then the
input channels will begin to
flicker.
OUT
IN
1 2 3 4
1 2 3 4
2. Press the NO.1 key of the
Input channel.
3. Press the STO key on the
front panel. The Store
Memory begins to flicker
about 8 seconds.
OUT
IN
1 2 3 4
1 2 3 4
4. Press the NO.1 key of the
output channel to save the
setting in the NO.1
channcel.
5. Press the ALL key on the
front panel, and then press
the OFF key to cancel the
setting.
6. Press the RCL key on the
front panel, The Recall
Memory begins to flicker
about 8 seconds.
OUT
IN
1 2 3 4
1 2 3 4
7. Press the NO.1 key of the
output channel to Load the
previously saving.
