Maintenance
6. Using a cross-head screwdriver, remove the two screws from
the lamp holder.
7. Lift out the lamp holder upwards.
8. Turn the lamp holder so that the connector with the cable
guide points forwards.
9. Push the clamp slide as far as possible to the right (Step 1).
10. Grasp the connector along with the lamp, pulling it out of the
lamp holder (Step 2).
11. Release the connector from the lamp (Step 3).
Figure 5 Lamp replacement
1 Lamp holder 3 Lamp
2 Clamp slide 4 Connector
