INITIAL START-UP

31. Press the

down ▼ arrow key until CAL

Voltage 60%

is displayed.

32. Press the CHANGE key. CAL Voltage 60%

will begin to flash.

33. The oxygen level at the 60% valve position

should be as shown below. Also, ensure that
the carbon monoxide (CO) and nitrogen
oxide (NOx) readings do not exceed the
values shown.

Combustion Oxygen Level at

60% Valve Position

Oxygen %

± 0.2

Carbon

Monoxide

NOx

6.3 %

<50 ppm

<30 ppm

34. If the oxygen level is not within the specified

range, adjust the level using the ▲ and ▼
arrow keys. This will adjust the output
voltage to the blower motor as indicated on
the display. Pressing the ▲ arrow key
increases the oxygen level and pressing the
▼ arrow key decreases the oxygen level.

35. Once the oxygen level is within the specified

range at 60%, press the ENTER key to store
the selected blower output voltage for the
60% valve position.

36. Press the ▲ arrow key until SET Valve

Position

appears on the C-MORE display.

37. Press the CHANGE key. SET Valve Position

will begin to flash.

38. Press the ▼ arrow key until the SET Valve

Position

reads 45%, then press the ENTER

key.

39. Press the

▼ arrow key until CAL Voltage

45%

is displayed.

40. Press the CHANGE key. CAL Voltage 45%

will begin to flash.

41. The oxygen level at the 45% valve position

should be as shown below. Also, ensure that
the carbon monoxide (CO) and nitrogen
oxide (NOx) readings do not exceed the
values shown.


Combustion Oxygen Level at

45% Valve Position

Oxygen %

± 0.2

Carbon

Monoxide

NOx

7.0 %

<50 ppm

<30 ppm


42. If the oxygen level is not within the specified

range, adjust the level using the ▲ and ▼
arrow keys. This will adjust the output
voltage to the blower motor as indicated on
the display. Pressing the ▲ arrow key
increases the oxygen level and pressing the
▼ arrow key decreases the oxygen level.

43. Once the oxygen level is within the specified

range at 45%, press the ENTER key to store
the selected blower output voltage for the
45% valve position.

44. Press the ▲ arrow key until SET Valve

Position

appears on the C-MORE display.

45. Press the CHANGE key. SET Valve Position

will begin to flash.

46. Press the ▼ arrow key until the SET Valve

Position

reads 30%, then press the ENTER

key.

47. Press the

▼ arrow key until CAL Voltage

30%

is displayed.

48. Press the CHANGE key. CAL Voltage 30%

will begin to flash.

49. The oxygen level at the 30% valve position

should be as shown below. Also, ensure that
the carbon monoxide (CO) and nitrogen
oxide (NOx) readings do not exceed the
values shown.

Combustion Oxygen Level at

30% Valve Position

Oxygen %

± 0.2

Carbon

Monoxide

NOx

7.0 %

<50 ppm

<30 ppm

50. If the oxygen level is not within the specified

range, adjust the level using the ▲ and ▼
arrow keys. This will adjust the output
voltage to the blower motor as indicated on
the display. Pressing the ▲ arrow key
increases the oxygen level and pressing the
▼ arrow key decreases the oxygen level.

51. Once the oxygen level is within the specified

range at 30%, press the ENTER key to store
the selected blower output voltage for the
30% valve position.

52. Press the ▲ arrow key until SET Valve

Position

appears on the C-MORE display.

53. Press the CHANGE key. SET Valve Position

will begin to flash.

54. Press the ▼ arrow key until the SET Valve

Position

reads 16%, then press the ENTER

key.

4-5
