APPENDIX F
AERCO INTERNATIONAL, INC.
NORTHVALE, NJ 07647
BENCHMARK 1.5 LOW NOx
BOILER PARTS LIST
(5) PART OF GAS TRAIN ASSY.
(4)ONLY NEEDED ON DUAL FUEL
FOR PICTORAL PURPOSES ONLY,
FM GAS TRAIN (NON DUAL FUEL) IS SHOWN
-7 (150 PSI RELIEF VALVE SETTING)
-6 (60,75,100 & 125 PSI RELIEF VALVE SETTING)
-5 (30 AND 50 PSI RELIEF VALVE SETTING)
NOT SHOWN IN DRAWING
NOTES:
(3)
(2)
(1)
TWO (2) REQUIRED FOR DUAL FUEL BMK1.5 LN (6)
(6)
(7) SEE DRAWING AP-A-833 FOR DUAL FUEL DETAILS
(2)
(1)
(1)
(5) (1)
(7) (5)
(1)
(1)(6)
(1)
(5)
(4) (1)
(4) (1)
(5) (4) (1)
(4)
(4)
(4) (1)
(4) (1)
D
PL - A - 157
(SHEET 2 OF 7)
DRAWN BY: SJD
DATE: 12/08/08
*NOT TO SCALE*
CONTROLS
ITEM PART NO. QTY DESCRIPTION
26 65090 1 DRIVE REACTOR
27 123966 1 OVER TEMP SWITCH AUTO
28 123552 1 OVER TEMP SWITCH MANUAL
29 61002-5 1 BLOCKED INLET SWITCH
30 60011-1 1 BLOWER PROOF SWITCH
31 161560 1 I /O WIRING BOX
32 181197 1 C-MORE CONTROL BOX
33 GP-122464 1 IGNITION TRANSFORMER
34 33048 1 VFD MOUNTING BRACKET
36 61024 1 AIR TEMP SENSOR
38 GP- 122569 1 IGNITION CABLE ASSY.
39 63016 1 BMK1.5LN SHELL HARNESS
40 63038 1 BLOWER HARNESS
42 64059 1 120V POWER WIRING BOX
43 161450 1 BMK1.5LN GAS TRAIN WIRING
HARNESS
44 122843 1 LOW WATER CUT-OFF
45 123449 1 SHELL TEMP. SENSOR
46 161521 1 THERMOWELL,
DUAL AQUASTAT BULB
47 61002-1 1 LOW GAS PRESSURE SWITCH
48
61002-12
1
HIGH GAS PRESSURE SWITCH
(NON DUAL FUEL)
61002-12 DUAL FUEL HGPS - NAT. GAS
61002-3 DUAL FUEL HGPS - PROPANE
49
OTHER ACCESORIES / PARTS
ITEM PART NO. QTY DESCRIPTION
50 69087- 1 PRESS./TEMP. GAUGE
51 SEE SD-A-751 1 PRESSURE RELIEF VALVE
52 92006-7 1 EXT. MANUAL SHUT-OFF VALVE
54 92006-7 1 1-1/2" NPT BALL VALVE
55 24060 1 COND. TRAP ASSEMBLY
OTHER DUAL FUEL COMPONENTS
ITEM PART NO. QTY DESCRIPTION
56 72031 1 "PROPANE" LABEL
57 72032 1 "NAT. GAS" LABEL
58 63032 1 DOUBLE GAS TRAIN WIRING
HARNESS
59 65024 1 FUEL SELECTOR SWITCH
60 33036 1
FUEL SELECTOR SWITCH
MOUNTINGBRACKET
61 72030 1 FUEL SELECTOR SWITCH LABEL
62 63034 1 DUAL FUEL WIRING HARNESS
63
SHEET METAL / PANEL ASSEMBLY
ITEM PART NO QTY DESCRIPTION
64 37017 1 LEFT REAR PANEL
65 37018 1 RIGHT REAR PANEL
66 49064 2 TOP RAIL
67 201233 1 MOUNTING PANEL
68 201113 1
FRONT PANEL
ENCLOSURE
69 201120 1 FRONT DOOR ASSY.
70 GP-122620 4 HANDLE
71 37019 2 TOP PANEL
72 37002 4 SIDE PANEL
73 74003 1 BMK1.5LN LOGO
OTHER PARTS
ITEM PART NO QTY DESCRIPTION
74 99017 1
GAS PRESSURE SNUBBER -
PART OF GAS TRAIN
F-9
