IV Series (Front Cover) - IM_E
Checking the Package Contents
Front cover (for replacement)
y OP-87461 x 1
Front cover
(for replacement) x 1
Mounting screw x 2
O-shaped ring
(Small x 2, Large x 1)
Hexagon wrench
(L-shaped) x 1
Instruction
manual x1
(This manual)
Replacing the front cover
Replace the front cover with the correct
procedure by following the precautions
below. Otherwise the enclosure rating
(IP67) may not be maintained.
y Do not let dust or dirt stick to the
O-shaped ring.
y Attach the O-shaped ring on the correct
position.
1
Remove the old front cover and the O-shaped
ring.
Dedicated screw
Front cover
O-shaped ring
(large)
O-shaped ring
(small)
2
Install the front cover after embedding the
O-shaped ring.
y Screw: Dedicated screw × 2
Use the attached dedicated screw.
y Tightening torque : 0.25 to 0.35 N·m
Dedicated screw
Front cover
O-shaped ring
(small)
O-shaped ring
(large)
Dimensions
φ50
27.1 0.4
