Section 1 General Information
1.1. INTRODUCTION
The Enviro™ Series instrument is designed for light capacity, general purpose use. It is also designed for use
in wash-down Environments.
Features
 The Indicator has a capacity setting of up to six digits, using a six-digit amber LED display.
 Annunciators include, Net Weight, Units, Under, Accept, Over, and Accumulation.
 Checkweigh mode can store up to four Checkweigh recipes.
1.2. SPECIFICATIONS
FEATURE DESCRIPTION
Display
 1.25” Segmented LED.
─
12 amber segments for under-weighments.
─
12 green segments for correct weighments.
─
12 red segments for over-weighments.
Display Update Rate
 0.1 – 1.0 second, selectable
Capacity
 Up to 999990 programmable
Resolution
 10,000 divisions, commercial.
 100,000 divisions, non-commercial.
 8,000,000 divisions, internal.
Division Sizes
 0.0001 – 50, selectable.
Load Cell(s)
 Up to four (4) 350 ohm cells.
Electrical
 120 VAC or 240 VAC, selectable.
Dimensions
 9.8” x 7.6” x 3.3”
Environment
 IP69K heavy washdown
Operating Temperature
Range
 -10º C to +40º C
 14º F – 104º F
Communications
 RS232 or RS485 bidirectional serial communications port
Units
 lbs, oz, kg, g and lbs/oz, or custom
Instrument Approvals
 CC: 09-024
 MC: Pending
 ETL: ETL Listing Pending
─
12/09 1 0596-0315-01 Rev B
