4.3.
KEYPAD FUNCTIONS, PROGRAMMING MODE.
This chart shows what action will be taken when a front panel key is pressed in the programming mode.
KEY
ACTION
1
No function in programming mode.
Exception, decrements selected digit when entering numeric data.
2
No function in programming mode.
Exception exits to done prompt when entering numeric data.
3
No function in programming mode.
Exception, moves flashing digit to far left position when entering numeric data.
4
No function in programming mode.
TARE
Scrolls backwards through the choices for each program step.
Exception, moves flashing digit left when entering numeric data.
ZERO
Accepts the displayed value and advances to the next program step like enter.
Exception, resets all digits to zeroes when entering numeric data.
PROGRAM
ENTER
Accepts the displayed value and advances to the next program step.
OVER/UNDER
NEXT
Scrolls forward through the choices for each program step.
Exception, moves flashing digit right when entering numeric data.
UNITS
Scrolls forward through the choices for each program step
Exception, increments digit when entering numeric data.
B/G
NET
Scrolls backward through programming steps.
Returns to the Weigh Mode after multiple pressings
.
No function in programming mode. Scrolls decimal point to the right in CAL mode.
4.4.
MENU ACCESS
This chart shows which menus can be accessed from the front panel based on the security level setting and the
internal jumper (JP1) position.
SL0
SL0
SL1
SL1
SL2
SL2
SL3
SL3
SL4
SL4
SL5
SL5
JP1
JP1
JP1
JP1
JP1
JP1
JP1
JP1
JP1
JP1
JP1
JP1
MENU
Out
In
Out
In
Out
In
Out
In
Out
In
Out
In
SEtUP
Y Y Y Y Y Y Y Y N N N N
ConFiG
Y N Y N Y N N N N N N N
APP
Y
Y Y Y Y Y Y Y N N N N
CAL
Y N Y N N N N N N N N N
