Hangar 9 Pulse XT 60 ARF User Manual

Page 35



Step 6

Attach the X-mount to the motor using the screws

provided with the motor.

Note: Use threadlock on the screws to

prevent them from vibrating loose in flight.



Step 7

Attach the motor to the firewall using four 2

-inch

(62mm) aluminum standoffs and four 8-32 x 3-inch

machine screws. Connect the motor to the ESC at this

time as well.

Note: Use threadlock on the screws to

prevent them from vibrating loose in flight.



Step 8

Secure the motor battery inside the fuselage using the

hook and loop straps.

Note: If the battery slides on the tray, it may

change the Center of Gravity. To prevent the

battery from moving, apply hook and loop

tape to the battery and the battery tray. This

will keep the battery from sliding on the tray.

Section 5: Electric Motor and Cowling Installation
