Step 7
Repeat Steps 3 through 7 to prepare a second aileron
servo. Note the direction of the servo arm in relationship
to the servo. You will be preparing a right and left aileron
servo, which are mirror images of each other.
Step 8
Thread one of the servo mounting screws into each of
the pre-drilled holes for the aileron servo as shown. This
will cut the threads into the wood in preparation for the
following step.
Step 9
After cutting the threads into the wood, apply a few
drops of thin CA to each of the four holes to harden the
surrounding wood. This will provide a better surface for
the screws and prevent vibration from loosening the
screws in flight.
Section 1: Aileron Servo Installation
